3D view of a scene that may contain different visualization objects which show the actual content of the scene. More...

#include <views/Visualization3DView.h>

Inheritance diagram for Visualization3DView:

[legend]

Signals
void	editorClosed (EditorPart *editor)

void	editorDestroyed (EditorPart *editor)

void	windowTitleChanged (EditorPartWindow *editor)

Public Member Functions
template<typename Reflector >
void	reflect (Reflector &r)

QGLWidget *	getGLRenderWidget ()
	Returns the GLWidget where this view renders its content (may be NULL if the view is uninitialized) More...

virtual QImage	captureContent ()
	Returns the content of the editor part as QImage. More...

virtual void	addVisualization (Visualization *vis)
	Adds an existing visualization to this view. More...

virtual void	moveUpVisualization (Visualization *vis)
	Change order of visualizations in the view, move the specified visualization up. More...

virtual void	moveDownVisualization (Visualization *vis)
	Change order of visualizations in the view, move the specified visualization down. More...

virtual void	addTool (VisualizationTool *tool)
	Adds an existing tool to this view. More...

virtual const Class &	supportedVisualizationClass () const
	Derived visualization views must return the base class of their supported visualizations. More...

virtual const Class &	supportedVisualizationToolClass () const
	Derived visualization views may return the base class of their supported tools. More...

virtual Ogre::SceneManager *	getSceneManager ()

virtual void	registerInteractionListener (InteractionListener3D *listener)

virtual void	removeInteractionListener (InteractionListener3D *listener)

virtual std::set< InteractionListener3D * >	getInteractionListeners ()

virtual const std::string &	getFixedFrame () const

virtual const std::string &	getCameraFrame () const

virtual const Camera &	getCamera () const
	Obtains the current camera settings (position, orientation, etc.) of the views own camera. More...

virtual void	setCamera (const Camera &camera)

virtual Ogre::Camera *	acquireCamera (boost::function< void()> lostCameraCallback=boost::function< void()>())
	Requests the camera of the visualization site. More...

virtual void	releaseCamera ()
	Releases a camera that previously was acquired. More...

void	reflect (XMLDeserializer &r)
	Specialization of reflect method for XML. More...

void	reflect (XMLSerializer &r)
	Specialization of reflect method for XML. More...

virtual void	removeVisualization (Visualization *vis)
	Remove the specified visualization from this view. More...

const std::list< Visualization * > &	getVisualizations () const

const std::vector< VisualizationTool * > &	getTools () const

VisualizationControlPage *	getControl ()
	Returns pointer to VisualizationControlPage (or NULL, if no such page was created yet. More...

virtual Object *	getAdapter (const Class &adapter)
	Returns an object which is an instance of the given class associated with this object. More...

virtual const Class &	defaultVisualizationClass () const
	If a default visualization class is provided, this class is used to instantiate a default visualization for data objects, no other specialized visualization is found for. More...

void	setUpdateInterval (int interval)

int	getUpdateInterval ()

VisualizationTool *	getActiveTool ()
	Returns the current active tool, or NULL of no tool is active. More...

void	activateTool (VisualizationTool *tool)

void	setOfferAuxiliaryVisualizations (bool on)

virtual void	init (IWorkbenchPartSite *site)
	Is called by the workbench. More...

IWorkbenchPartSite *	getSite ()

void	setWidget (QWidget *widget)

QWidget *	widget () const

EditorPartTitleBar *	getTitleBar ()

void	undock ()
	Undocks the window from the EditorPartArea and makes it floating. More...

void	dock ()
	Docks the window back to the EditorPartArea. More...

bool	isDocked () const
	Returns true, if the window is docked in the EditorPartArea. More...

void	setOnTop (bool onTop)
	Makes the window stay on top of other windows. More...

bool	isOnTop () const
	Returns true, if the window stays on top of other windows. More...

void	showDecorations (bool show)

void	setAutoHideDecorations (bool on)

virtual void	activate ()
	Is called by the Workbench to inform the Part that is being activated by the user. More...

virtual void	deactivate ()
	Is called by the Workbench to inform the Part that is being deactivated since another Part got the focus. More...

bool	isActivated () const
	Returns true if this ViewPart currently has the focus and hence the users attention. More...

Class const &	getClass () const
	call the virtual internalGetClass(). More...

virtual void	setCamera (const Camera &camera)=0
	Sets the current camera settings (position, orientation, etc.) of the views own camera. More...

Static Public Member Functions
static PseudoClass const &	CLASS ()

Protected Slots
void	onMinimized ()

void	onMaximized ()

void	onRestored ()

void	onUndock ()

void	onDock ()

void	onOnTop (bool onTop)

Protected Member Functions
virtual void	update (Duration dt)
	Is called by this class within the update timer event to update the view. More...

void	changeLightColor ()

virtual void	changeLightDirection ()

void	changeAmbientLight ()

virtual QWidget *	createVisualizationPart ()

virtual void	resetView ()

virtual void	saveContentToFile ()

virtual void	setCameraFrame (const TransformProperty &frame)

virtual QWidget *	createPartControl ()
	Must be overloaded in subclasses to create the actual widget for this EditorPart. More...

void	startUpdateTimer ()

virtual void	timerEvent (QTimerEvent *)

bool	eventFilter (QObject obj, QEvent event)

void	keyPressEvent (QKeyEvent *event)

void	keyReleaseEvent (QKeyEvent *event)

void	focusOutEvent (QFocusEvent *event)

std::string	getChannelIDFromMimeData (const QMimeData *mimeData)

std::list< ClassProxy >	getVisualizationsFor (const std::string &channelID)

void	dragEnterEventImpl (QDragEnterEvent *event)

void	dropEventImpl (QDropEvent event, QWidget widget)

void	destroyVisualizations ()

void	destroyTools ()

QMenu *	getViewMenu ()
	Returns the optional editor menu that is shown when the user clicks the editor menu tool button. More...

virtual void	closeEvent (QCloseEvent *)

virtual void	paintEvent (QPaintEvent *paintEvent)

virtual void	changeEvent (QEvent *event)

void	setActive (bool activate)

virtual void	windowStateChanged (Qt::WindowStates oldState, Qt::WindowStates newState)

void	updateDecorations ()

void	updateStateButtons ()

virtual Class const &	internalGetClass () const =0

Protected Attributes
TransformProperty	mFixedFrame

TransformProperty	mCameraFrame

Friends
class	UI

class	RenderModeTechniqueMod

class	RenderQueueSorter

Detailed Description

3D view of a scene that may contain different visualization objects which show the actual content of the scene.

Member Function Documentation

◆ reflect() [1/3]

void reflect ( Reflector & r )

inline

◆ getGLRenderWidget()

QGLWidget* getGLRenderWidget ( )

Returns the GLWidget where this view renders its content (may be NULL if the view is uninitialized)

◆ captureContent()

virtual QImage captureContent ( )

virtual

Returns the content of the editor part as QImage.

Can be reimplemented by subclasses to provide special capturing techniques that are e.g. required by OpenQL widgets.

Reimplemented from EditorPart.

◆ addVisualization()

virtual void addVisualization ( Visualization * vis )

virtual

Adds an existing visualization to this view.

The view will take ownership of the visualization and will destroy it upon its own deletion.

Reimplemented from VisualizationView.

◆ moveUpVisualization()

virtual void moveUpVisualization ( Visualization * vis )

virtual

Change order of visualizations in the view, move the specified visualization up.

The base VisualizationView just changes the order in the stored list of visualizations. Subclasses should overwrite this method to adapt their respective GUI accordingly.

Reimplemented from VisualizationView.

◆ moveDownVisualization()

virtual void moveDownVisualization ( Visualization * vis )

virtual

Change order of visualizations in the view, move the specified visualization down.

The base VisualizationView just changes the order in the stored list of visualizations. Subclasses should overwrite this method to adapt their respective GUI accordingly.

Reimplemented from VisualizationView.

◆ addTool()

virtual void addTool ( VisualizationTool * tool )

virtual

Adds an existing tool to this view.

The view will take ownership of the tool and will destroy it upon its own deletion.

Reimplemented from VisualizationView.

◆ supportedVisualizationClass()

virtual const Class& supportedVisualizationClass ( ) const

virtual

Derived visualization views must return the base class of their supported visualizations.

Implements VisualizationView.

◆ supportedVisualizationToolClass()

virtual const Class& supportedVisualizationToolClass ( ) const

virtual

Derived visualization views may return the base class of their supported tools.

The default implementation returns a null-class to indicate that no tools are supported.

Reimplemented from VisualizationView.

◆ update()

virtual void update ( Duration dt )

protectedvirtual

Is called by this class within the update timer event to update the view.

The visualizations of the view have been updated before this method is called. The update cycle must be enabled by calling startUpdateTimer() after the derived class and its GUI components have been enabled

Implements VisualizationView.

◆ changeLightColor()

void changeLightColor ( )

protected

◆ changeLightDirection()

virtual void changeLightDirection ( )

protectedvirtual

◆ changeAmbientLight()

void changeAmbientLight ( )

protected

◆ createVisualizationPart()

virtual QWidget* createVisualizationPart ( )

protectedvirtual

Implements VisualizationView.

◆ resetView()

virtual void resetView ( )

protectedvirtual

Reimplemented from VisualizationView.

◆ saveContentToFile()

virtual void saveContentToFile ( )

protectedvirtual

Reimplemented from VisualizationView.

◆ setCameraFrame()

virtual void setCameraFrame ( const TransformProperty & frame )

protectedvirtual

Reimplemented from VisualizationViewTransformable.

◆ getSceneManager()

virtual Ogre::SceneManager* getSceneManager ( )

virtual

Implements IVisualization3DSite.

◆ registerInteractionListener()

virtual void registerInteractionListener ( InteractionListener3D * listener )

virtual

Implements IVisualization3DSite.

◆ removeInteractionListener()

virtual void removeInteractionListener ( InteractionListener3D * listener )

virtual

Implements IVisualization3DSite.

◆ getInteractionListeners()

virtual std::set<InteractionListener3D*> getInteractionListeners ( )

virtual

Implements IVisualization3DSite.

◆ getFixedFrame()

virtual const std::string& getFixedFrame ( ) const

inlinevirtual

Implements IVisualizationSiteTransformable.

◆ getCameraFrame()

virtual const std::string& getCameraFrame ( ) const

inlinevirtual

Implements IVisualizationSiteTransformable.

◆ getCamera()

virtual const Camera& getCamera ( ) const

virtual

Obtains the current camera settings (position, orientation, etc.) of the views own camera.

Implements IVisualization3DSite.

◆ setCamera() [1/2]

virtual void setCamera ( const Camera & camera )

virtual

◆ acquireCamera()

virtual Ogre::Camera* acquireCamera ( boost::function< void()> lostCameraCallback = boost::function< void()>() )

virtual

Requests the camera of the visualization site.

This method can be called by visualizations or tools to get direct access to the camera. The visualization/tool is then responsible for updating the cameras position (e.g. in its update() method). Optionally, a callback can be specified, that is called if another visualization/tool has requested the camera. The visualization finally should release the camera by calling releaseCamera().

Implements IVisualization3DSite.

◆ releaseCamera()

virtual void releaseCamera ( )

virtual

Releases a camera that previously was acquired.

Implements IVisualization3DSite.

◆ reflect() [2/3]

void reflect ( XMLDeserializer & r )

inherited

Specialization of reflect method for XML.

◆ reflect() [3/3]

void reflect ( XMLSerializer & r )

inherited

Specialization of reflect method for XML.

◆ removeVisualization()

virtual void removeVisualization ( Visualization * vis )

virtualinherited

Remove the specified visualization from this view.

The view will give up its ownership of the visualization and the Visualization must be destroyed outside of this view.

◆ getVisualizations()

const std::list<Visualization*>& getVisualizations ( ) const

inherited

◆ getTools()

const std::vector<VisualizationTool*>& getTools ( ) const

inherited

◆ getControl()

VisualizationControlPage* getControl ( )

inherited

Returns pointer to VisualizationControlPage (or NULL, if no such page was created yet.

◆ getAdapter()

virtual Object* getAdapter ( const Class & adapter )

virtualinherited

Returns an object which is an instance of the given class associated with this object.

Returns nullptr if no such object can be found. The implementation if IAdaptable is responsible for destroying the instance of the created object.

Reimplemented from WorkbenchPart.

◆ defaultVisualizationClass()

virtual const Class& defaultVisualizationClass ( ) const

inlinevirtualinherited

If a default visualization class is provided, this class is used to instantiate a default visualization for data objects, no other specialized visualization is found for.

If no default visualization class exists, such data objects can not be visualized (the default behavior).

◆ createPartControl()

virtual QWidget* createPartControl ( )

protectedvirtualinherited

Must be overloaded in subclasses to create the actual widget for this EditorPart.

This EditorPart should be set as parent for the created widget.

Implements EditorPart.

◆ setUpdateInterval()

void setUpdateInterval ( int interval )

inherited

◆ getUpdateInterval()

int getUpdateInterval ( )

inherited

◆ getActiveTool()

VisualizationTool* getActiveTool ( )

inlineinherited

Returns the current active tool, or NULL of no tool is active.

◆ activateTool()

void activateTool ( VisualizationTool * tool )

inherited

◆ setOfferAuxiliaryVisualizations()

void setOfferAuxiliaryVisualizations ( bool on )

inlineinherited

◆ startUpdateTimer()

void startUpdateTimer ( )

protectedinherited

◆ timerEvent()

virtual void timerEvent ( QTimerEvent * )

protectedvirtualinherited

◆ eventFilter()

bool eventFilter	(	QObject *	obj,
		QEvent *	event
	)

protectedinherited

◆ keyPressEvent()

void keyPressEvent ( QKeyEvent * event )

protectedinherited

◆ keyReleaseEvent()

void keyReleaseEvent ( QKeyEvent * event )

protectedinherited

◆ focusOutEvent()

void focusOutEvent ( QFocusEvent * event )

protectedinherited

◆ getChannelIDFromMimeData()

std::string getChannelIDFromMimeData ( const QMimeData * mimeData )

protectedinherited

◆ getVisualizationsFor()

std::list<ClassProxy> getVisualizationsFor ( const std::string & channelID )

protectedinherited

◆ dragEnterEventImpl()

void dragEnterEventImpl ( QDragEnterEvent * event )

protectedinherited

◆ dropEventImpl()

void dropEventImpl	(	QDropEvent *	event,
		QWidget *	widget
	)

protectedinherited

◆ destroyVisualizations()

void destroyVisualizations ( )

protectedinherited

◆ destroyTools()

void destroyTools ( )

protectedinherited

◆ init()

virtual void init ( IWorkbenchPartSite * site )

virtualinherited

Is called by the workbench.

The WorkbenchPart should initialize itself and my store the pointer tothe IWorkbenchPartSite interface for later use.

Implements WorkbenchPart.

◆ getSite()

IWorkbenchPartSite* getSite ( )

inherited

◆ getViewMenu()

QMenu* getViewMenu ( )

protectedinherited

Returns the optional editor menu that is shown when the user clicks the editor menu tool button.

An EditorPart can add items to this menu within it's createPartControl() method, by calling this method and populating items to the menu.

◆ closeEvent()

virtual void closeEvent ( QCloseEvent * )

protectedvirtualinherited

◆ editorClosed

void editorClosed ( EditorPart * editor )

signalinherited

◆ editorDestroyed

void editorDestroyed ( EditorPart * editor )

signalinherited

◆ setWidget()

void setWidget ( QWidget * widget )

inherited

◆ widget()

QWidget* widget ( ) const

inherited

◆ getTitleBar()

EditorPartTitleBar* getTitleBar ( )

inherited

◆ undock()

void undock ( )

inlineinherited

Undocks the window from the EditorPartArea and makes it floating.

◆ dock()

void dock ( )

inlineinherited

Docks the window back to the EditorPartArea.

◆ isDocked()

bool isDocked ( ) const

inlineinherited

Returns true, if the window is docked in the EditorPartArea.

◆ setOnTop()

void setOnTop ( bool onTop )

inlineinherited

Makes the window stay on top of other windows.

◆ isOnTop()

bool isOnTop ( ) const

inlineinherited

Returns true, if the window stays on top of other windows.

◆ showDecorations()

void showDecorations ( bool show )

inherited

◆ setAutoHideDecorations()

void setAutoHideDecorations ( bool on )

inherited

◆ paintEvent()

virtual void paintEvent ( QPaintEvent * paintEvent )

protectedvirtualinherited

◆ changeEvent()

virtual void changeEvent ( QEvent * event )

protectedvirtualinherited

◆ setActive()

void setActive ( bool activate )

protectedinherited

◆ windowStateChanged()

virtual void windowStateChanged	(	Qt::WindowStates	oldState,
		Qt::WindowStates	newState
	)

protectedvirtualinherited

◆ updateDecorations()

void updateDecorations ( )

protectedinherited

◆ updateStateButtons()

void updateStateButtons ( )

protectedinherited

◆ onMinimized

void onMinimized ( )

protectedslotinherited

◆ onMaximized

void onMaximized ( )

protectedslotinherited

◆ onRestored

void onRestored ( )

protectedslotinherited

◆ onUndock

void onUndock ( )

protectedslotinherited

◆ onDock

void onDock ( )

protectedslotinherited

◆ onOnTop

void onOnTop ( bool onTop )

protectedslotinherited

◆ windowTitleChanged

void windowTitleChanged ( EditorPartWindow * editor )

signalinherited

◆ activate()

virtual void activate ( )

virtualinherited

Is called by the Workbench to inform the Part that is being activated by the user.

Implements IWorkbenchPart.

Reimplemented in ViewPart.

◆ deactivate()

virtual void deactivate ( )

virtualinherited

Is called by the Workbench to inform the Part that is being deactivated since another Part got the focus.

Implements IWorkbenchPart.

Reimplemented in ViewPart.

◆ isActivated()

bool isActivated ( ) const

inlineinherited

Returns true if this ViewPart currently has the focus and hence the users attention.

◆ getClass()

Class const& getClass ( ) const

inlineinherited

call the virtual internalGetClass().

◆ CLASS()

static PseudoClass const& CLASS ( )

inlinestaticinherited

◆ internalGetClass()

virtual Class const& internalGetClass ( ) const

protectedpure virtualinherited

◆ setCamera() [2/2]

virtual void setCamera ( const Camera & camera )

pure virtualinherited

Sets the current camera settings (position, orientation, etc.) of the views own camera.

Implemented in Visualization3DContainer.

Friends And Related Function Documentation

◆ UI

friend class UI

friend

◆ RenderModeTechniqueMod

friend class RenderModeTechniqueMod

friend

◆ RenderQueueSorter

friend class RenderQueueSorter

friend

Member Data Documentation

◆ mFixedFrame

TransformProperty mFixedFrame

protectedinherited

◆ mCameraFrame

TransformProperty mCameraFrame

protectedinherited

The documentation for this class was generated from the following file:

gui/include/views/Visualization3DView.h

Signals

Public Member Functions

Static Public Member Functions

Protected Slots

Protected Member Functions

Protected Attributes

Friends

Detailed Description

Member Function Documentation

◆ reflect() [1/3]

◆ getGLRenderWidget()

◆ captureContent()

◆ addVisualization()

◆ moveUpVisualization()

◆ moveDownVisualization()

◆ addTool()

◆ supportedVisualizationClass()

◆ supportedVisualizationToolClass()

◆ update()

◆ changeLightColor()

◆ changeLightDirection()

◆ changeAmbientLight()

◆ createVisualizationPart()

◆ resetView()

◆ saveContentToFile()

◆ setCameraFrame()

◆ getSceneManager()

◆ registerInteractionListener()

◆ removeInteractionListener()

◆ getInteractionListeners()

◆ getFixedFrame()

◆ getCameraFrame()

◆ getCamera()

◆ setCamera() [1/2]

◆ acquireCamera()

◆ releaseCamera()

◆ reflect() [2/3]

◆ reflect() [3/3]

◆ removeVisualization()

◆ getVisualizations()

◆ getTools()

◆ getControl()

◆ getAdapter()

◆ defaultVisualizationClass()

◆ createPartControl()

◆ setUpdateInterval()

◆ getUpdateInterval()

◆ getActiveTool()

◆ activateTool()

◆ setOfferAuxiliaryVisualizations()

◆ startUpdateTimer()

◆ timerEvent()

◆ eventFilter()

◆ keyPressEvent()

◆ keyReleaseEvent()

◆ focusOutEvent()

◆ getChannelIDFromMimeData()

◆ getVisualizationsFor()

◆ dragEnterEventImpl()

◆ dropEventImpl()

◆ destroyVisualizations()

◆ destroyTools()

◆ init()

◆ getSite()

◆ getViewMenu()

◆ closeEvent()

◆ editorClosed

◆ editorDestroyed

◆ setWidget()

◆ widget()

◆ getTitleBar()

◆ undock()

◆ dock()

◆ isDocked()

◆ setOnTop()

◆ isOnTop()

◆ showDecorations()

◆ setAutoHideDecorations()

◆ paintEvent()

◆ changeEvent()
