Abstract base class for 2D, 3D, text and plot visualization views (namely Visualization2DView and Visualization3DView...) that support a target frame. More...

#include <views/VisualizationView.h>

Inheritance diagram for VisualizationViewTransformable:

[legend]

Signals
void	editorClosed (EditorPart *editor)

void	editorDestroyed (EditorPart *editor)

void	windowTitleChanged (EditorPartWindow *editor)

Public Member Functions
	VisualizationViewTransformable ()

virtual	~VisualizationViewTransformable ()

template<typename Reflector >
void	reflect (Reflector &r)

void	reflect (XMLDeserializer &r)
	Specialization of reflect method for XML. More...

void	reflect (XMLSerializer &r)
	Specialization of reflect method for XML. More...

virtual void	addVisualization (Visualization *vis)
	Adds an existing visualization to this view. More...

virtual void	removeVisualization (Visualization *vis)
	Remove the specified visualization from this view. More...

virtual void	moveUpVisualization (Visualization *vis)
	Change order of visualizations in the view, move the specified visualization up. More...

virtual void	moveDownVisualization (Visualization *vis)
	Change order of visualizations in the view, move the specified visualization down. More...

const std::list< Visualization * > &	getVisualizations () const

virtual void	addTool (VisualizationTool *tool)
	Adds an existing tool to this view. More...

const std::vector< VisualizationTool * > &	getTools () const

VisualizationControlPage *	getControl ()
	Returns pointer to VisualizationControlPage (or NULL, if no such page was created yet. More...

virtual Object *	getAdapter (const Class &adapter)
	Returns an object which is an instance of the given class associated with this object. More...

virtual const Class &	supportedVisualizationClass () const =0
	Derived visualization views must return the base class of their supported visualizations. More...

virtual const Class &	defaultVisualizationClass () const
	If a default visualization class is provided, this class is used to instantiate a default visualization for data objects, no other specialized visualization is found for. More...

virtual const Class &	supportedVisualizationToolClass () const
	Derived visualization views may return the base class of their supported tools. More...

void	setUpdateInterval (int interval)

int	getUpdateInterval ()

VisualizationTool *	getActiveTool ()
	Returns the current active tool, or NULL of no tool is active. More...

void	activateTool (VisualizationTool *tool)

void	setOfferAuxiliaryVisualizations (bool on)

virtual void	init (IWorkbenchPartSite *site)
	Is called by the workbench. More...

IWorkbenchPartSite *	getSite ()

virtual QImage	captureContent ()
	Returns the content of the editor part as QImage. More...

void	setWidget (QWidget *widget)

QWidget *	widget () const

EditorPartTitleBar *	getTitleBar ()

void	undock ()
	Undocks the window from the EditorPartArea and makes it floating. More...

void	dock ()
	Docks the window back to the EditorPartArea. More...

bool	isDocked () const
	Returns true, if the window is docked in the EditorPartArea. More...

void	setOnTop (bool onTop)
	Makes the window stay on top of other windows. More...

bool	isOnTop () const
	Returns true, if the window stays on top of other windows. More...

void	showDecorations (bool show)

void	setAutoHideDecorations (bool on)

virtual void	activate ()
	Is called by the Workbench to inform the Part that is being activated by the user. More...

virtual void	deactivate ()
	Is called by the Workbench to inform the Part that is being deactivated since another Part got the focus. More...

bool	isActivated () const
	Returns true if this ViewPart currently has the focus and hence the users attention. More...

Class const &	getClass () const
	call the virtual internalGetClass(). More...

Static Public Member Functions
static PseudoClass const &	CLASS ()

Protected Slots
void	onMinimized ()

void	onMaximized ()

void	onRestored ()

void	onUndock ()

void	onDock ()

void	onOnTop (bool onTop)

Protected Member Functions
virtual void	setCameraFrame (const TransformProperty &frame)

virtual QWidget *	createPartControl ()
	Must be overloaded in subclasses to create the actual widget for this EditorPart. More...

virtual QWidget *	createVisualizationPart ()=0

virtual void	resetView ()

virtual void	saveContentToFile ()

virtual void	update (Duration dt)=0
	Is called by this class within the update timer event to update the view. More...

void	startUpdateTimer ()

virtual void	timerEvent (QTimerEvent *)

bool	eventFilter (QObject obj, QEvent event)

void	keyPressEvent (QKeyEvent *event)

void	keyReleaseEvent (QKeyEvent *event)

void	focusOutEvent (QFocusEvent *event)

std::string	getChannelIDFromMimeData (const QMimeData *mimeData)

std::list< ClassProxy >	getVisualizationsFor (const std::string &channelID)

void	dragEnterEventImpl (QDragEnterEvent *event)

void	dropEventImpl (QDropEvent event, QWidget widget)

void	destroyVisualizations ()

void	destroyTools ()

QMenu *	getViewMenu ()
	Returns the optional editor menu that is shown when the user clicks the editor menu tool button. More...

virtual void	closeEvent (QCloseEvent *)

virtual void	paintEvent (QPaintEvent *paintEvent)

virtual void	changeEvent (QEvent *event)

void	setActive (bool activate)

virtual void	windowStateChanged (Qt::WindowStates oldState, Qt::WindowStates newState)

void	updateDecorations ()

void	updateStateButtons ()

virtual Class const &	internalGetClass () const =0

Protected Attributes
TransformProperty	mFixedFrame

TransformProperty	mCameraFrame

Detailed Description

Abstract base class for 2D, 3D, text and plot visualization views (namely Visualization2DView and Visualization3DView...) that support a target frame.

Constructor & Destructor Documentation

◆ VisualizationViewTransformable()

VisualizationViewTransformable ( )

◆ ~VisualizationViewTransformable()

virtual ~VisualizationViewTransformable ( )

virtual

Member Function Documentation

◆ reflect() [1/3]

void reflect ( Reflector & r )

inline

◆ setCameraFrame()

virtual void setCameraFrame ( const TransformProperty & frame )

inlineprotectedvirtual

Reimplemented in Visualization3DView.

◆ reflect() [2/3]

void reflect ( XMLDeserializer & r )

inherited

Specialization of reflect method for XML.

◆ reflect() [3/3]

void reflect ( XMLSerializer & r )

inherited

Specialization of reflect method for XML.

◆ addVisualization()

virtual void addVisualization ( Visualization * vis )

virtualinherited

Adds an existing visualization to this view.

The view will take ownership of the visualization and will destroy it upon its own deletion.

Reimplemented in Visualization3DView, and Visualization2DView.

◆ removeVisualization()

virtual void removeVisualization ( Visualization * vis )

virtualinherited

Remove the specified visualization from this view.

The view will give up its ownership of the visualization and the Visualization must be destroyed outside of this view.

◆ moveUpVisualization()

virtual void moveUpVisualization ( Visualization * vis )

virtualinherited

Change order of visualizations in the view, move the specified visualization up.

The base VisualizationView just changes the order in the stored list of visualizations. Subclasses should overwrite this method to adapt their respective GUI accordingly.

Reimplemented in Visualization3DView, and Visualization2DView.

◆ moveDownVisualization()

virtual void moveDownVisualization ( Visualization * vis )

virtualinherited

Change order of visualizations in the view, move the specified visualization down.

The base VisualizationView just changes the order in the stored list of visualizations. Subclasses should overwrite this method to adapt their respective GUI accordingly.

Reimplemented in Visualization3DView, and Visualization2DView.

◆ getVisualizations()

const std::list<Visualization*>& getVisualizations ( ) const

inherited

◆ addTool()

virtual void addTool ( VisualizationTool * tool )

virtualinherited

Adds an existing tool to this view.

The view will take ownership of the tool and will destroy it upon its own deletion.

Reimplemented in Visualization3DView, and Visualization2DView.

◆ getTools()

const std::vector<VisualizationTool*>& getTools ( ) const

inherited

◆ getControl()

VisualizationControlPage* getControl ( )

inherited

Returns pointer to VisualizationControlPage (or NULL, if no such page was created yet.

◆ getAdapter()

virtual Object* getAdapter ( const Class & adapter )

virtualinherited

Returns an object which is an instance of the given class associated with this object.

Returns nullptr if no such object can be found. The implementation if IAdaptable is responsible for destroying the instance of the created object.

Reimplemented from WorkbenchPart.

◆ supportedVisualizationClass()

virtual const Class& supportedVisualizationClass ( ) const

pure virtualinherited

Derived visualization views must return the base class of their supported visualizations.

Implemented in Visualization3DView, and Visualization2DView.

◆ defaultVisualizationClass()

virtual const Class& defaultVisualizationClass ( ) const

inlinevirtualinherited

If a default visualization class is provided, this class is used to instantiate a default visualization for data objects, no other specialized visualization is found for.

If no default visualization class exists, such data objects can not be visualized (the default behavior).

◆ supportedVisualizationToolClass()

virtual const Class& supportedVisualizationToolClass ( ) const

inlinevirtualinherited

Derived visualization views may return the base class of their supported tools.

The default implementation returns a null-class to indicate that no tools are supported.

Reimplemented in Visualization3DView, and Visualization2DView.

◆ createPartControl()

virtual QWidget* createPartControl ( )

protectedvirtualinherited

Must be overloaded in subclasses to create the actual widget for this EditorPart.

This EditorPart should be set as parent for the created widget.

Implements EditorPart.

◆ createVisualizationPart()

virtual QWidget* createVisualizationPart ( )

protectedpure virtualinherited

Implemented in Visualization3DView, and Visualization2DView.

◆ resetView()

virtual void resetView ( )

protectedvirtualinherited

Reimplemented in Visualization3DView, and Visualization2DView.

◆ saveContentToFile()

virtual void saveContentToFile ( )

protectedvirtualinherited

Reimplemented in Visualization3DView, and Visualization2DView.

◆ update()

virtual void update ( Duration dt )

protectedpure virtualinherited

Is called by this class within the update timer event to update the view.

The visualizations of the view have been updated before this method is called. The update cycle must be enabled by calling startUpdateTimer() after the derived class and its GUI components have been enabled

Implemented in Visualization3DView, and Visualization2DView.

◆ setUpdateInterval()

void setUpdateInterval ( int interval )

inherited

◆ getUpdateInterval()

int getUpdateInterval ( )

inherited

◆ getActiveTool()

VisualizationTool* getActiveTool ( )

inlineinherited

Returns the current active tool, or NULL of no tool is active.

◆ activateTool()

void activateTool ( VisualizationTool * tool )

inherited

◆ setOfferAuxiliaryVisualizations()

void setOfferAuxiliaryVisualizations ( bool on )

inlineinherited

◆ startUpdateTimer()

void startUpdateTimer ( )

protectedinherited

◆ timerEvent()

virtual void timerEvent ( QTimerEvent * )

protectedvirtualinherited

◆ eventFilter()

bool eventFilter	(	QObject *	obj,
		QEvent *	event
	)

protectedinherited

◆ keyPressEvent()

void keyPressEvent ( QKeyEvent * event )

protectedinherited

◆ keyReleaseEvent()

void keyReleaseEvent ( QKeyEvent * event )

protectedinherited

◆ focusOutEvent()

void focusOutEvent ( QFocusEvent * event )

protectedinherited

◆ getChannelIDFromMimeData()

std::string getChannelIDFromMimeData ( const QMimeData * mimeData )

protectedinherited

◆ getVisualizationsFor()

std::list<ClassProxy> getVisualizationsFor ( const std::string & channelID )

protectedinherited

◆ dragEnterEventImpl()

void dragEnterEventImpl ( QDragEnterEvent * event )

protectedinherited

◆ dropEventImpl()

void dropEventImpl	(	QDropEvent *	event,
		QWidget *	widget
	)

protectedinherited

◆ destroyVisualizations()

void destroyVisualizations ( )

protectedinherited

◆ destroyTools()

void destroyTools ( )

protectedinherited

◆ init()

virtual void init ( IWorkbenchPartSite * site )

virtualinherited

Is called by the workbench.

The WorkbenchPart should initialize itself and my store the pointer tothe IWorkbenchPartSite interface for later use.

Implements WorkbenchPart.

◆ getSite()

IWorkbenchPartSite* getSite ( )

inherited

◆ captureContent()

virtual QImage captureContent ( )

virtualinherited

Returns the content of the editor part as QImage.

Can be reimplemented by subclasses to provide special capturing techniques that are e.g. required by OpenQL widgets.

Reimplemented in Visualization3DView.

◆ getViewMenu()

QMenu* getViewMenu ( )

protectedinherited

Returns the optional editor menu that is shown when the user clicks the editor menu tool button.

An EditorPart can add items to this menu within it's createPartControl() method, by calling this method and populating items to the menu.

◆ closeEvent()

virtual void closeEvent ( QCloseEvent * )

protectedvirtualinherited

◆ editorClosed

void editorClosed ( EditorPart * editor )

signalinherited

◆ editorDestroyed

void editorDestroyed ( EditorPart * editor )

signalinherited

◆ setWidget()

void setWidget ( QWidget * widget )

inherited

◆ widget()

QWidget* widget ( ) const

inherited

◆ getTitleBar()

EditorPartTitleBar* getTitleBar ( )

inherited

◆ undock()

void undock ( )

inlineinherited

Undocks the window from the EditorPartArea and makes it floating.

◆ dock()

void dock ( )

inlineinherited

Docks the window back to the EditorPartArea.

◆ isDocked()

bool isDocked ( ) const

inlineinherited

Returns true, if the window is docked in the EditorPartArea.

◆ setOnTop()

void setOnTop ( bool onTop )

inlineinherited

Makes the window stay on top of other windows.

◆ isOnTop()

bool isOnTop ( ) const

inlineinherited

Returns true, if the window stays on top of other windows.

◆ showDecorations()

void showDecorations ( bool show )

inherited

◆ setAutoHideDecorations()

void setAutoHideDecorations ( bool on )

inherited

◆ paintEvent()

virtual void paintEvent ( QPaintEvent * paintEvent )

protectedvirtualinherited

◆ changeEvent()

virtual void changeEvent ( QEvent * event )

protectedvirtualinherited

◆ setActive()

void setActive ( bool activate )

protectedinherited

◆ windowStateChanged()

virtual void windowStateChanged	(	Qt::WindowStates	oldState,
		Qt::WindowStates	newState
	)

protectedvirtualinherited

◆ updateDecorations()

void updateDecorations ( )

protectedinherited

◆ updateStateButtons()

void updateStateButtons ( )

protectedinherited

◆ onMinimized

void onMinimized ( )

protectedslotinherited

◆ onMaximized

void onMaximized ( )

protectedslotinherited

◆ onRestored

void onRestored ( )

protectedslotinherited

◆ onUndock

void onUndock ( )

protectedslotinherited

◆ onDock

void onDock ( )

protectedslotinherited

◆ onOnTop

void onOnTop ( bool onTop )

protectedslotinherited

◆ windowTitleChanged

void windowTitleChanged ( EditorPartWindow * editor )

signalinherited

◆ activate()

virtual void activate ( )

virtualinherited

Is called by the Workbench to inform the Part that is being activated by the user.

Implements IWorkbenchPart.

Reimplemented in ViewPart.

◆ deactivate()

virtual void deactivate ( )

virtualinherited

Is called by the Workbench to inform the Part that is being deactivated since another Part got the focus.

Implements IWorkbenchPart.

Reimplemented in ViewPart.

◆ isActivated()

bool isActivated ( ) const

inlineinherited

Returns true if this ViewPart currently has the focus and hence the users attention.

◆ getClass()

Class const& getClass ( ) const

inlineinherited

call the virtual internalGetClass().

◆ CLASS()

static PseudoClass const& CLASS ( )

inlinestaticinherited

◆ internalGetClass()

virtual Class const& internalGetClass ( ) const

protectedpure virtualinherited

Member Data Documentation

◆ mFixedFrame

TransformProperty mFixedFrame

protected

◆ mCameraFrame

TransformProperty mCameraFrame

protected

The documentation for this class was generated from the following file:

gui/include/views/VisualizationView.h

Signals

Public Member Functions

Static Public Member Functions

Protected Slots

Protected Member Functions

Protected Attributes

Detailed Description

Constructor & Destructor Documentation

◆ VisualizationViewTransformable()

◆ ~VisualizationViewTransformable()

Member Function Documentation

◆ reflect() [1/3]

◆ setCameraFrame()

◆ reflect() [2/3]

◆ reflect() [3/3]

◆ addVisualization()

◆ removeVisualization()

◆ moveUpVisualization()

◆ moveDownVisualization()

◆ getVisualizations()

◆ addTool()

◆ getTools()

◆ getControl()

◆ getAdapter()

◆ supportedVisualizationClass()

◆ defaultVisualizationClass()

◆ supportedVisualizationToolClass()

◆ createPartControl()

◆ createVisualizationPart()

◆ resetView()

◆ saveContentToFile()

◆ update()

◆ setUpdateInterval()

◆ getUpdateInterval()

◆ getActiveTool()

◆ activateTool()

◆ setOfferAuxiliaryVisualizations()

◆ startUpdateTimer()

◆ timerEvent()

◆ eventFilter()

◆ keyPressEvent()

◆ keyReleaseEvent()

◆ focusOutEvent()

◆ getChannelIDFromMimeData()

◆ getVisualizationsFor()

◆ dragEnterEventImpl()

◆ dropEventImpl()

◆ destroyVisualizations()

◆ destroyTools()

◆ init()

◆ getSite()

◆ captureContent()

◆ getViewMenu()

◆ closeEvent()

◆ editorClosed

◆ editorDestroyed

◆ setWidget()

◆ widget()

◆ getTitleBar()

◆ undock()

◆ dock()

◆ isDocked()

◆ setOnTop()

◆ isOnTop()

◆ showDecorations()

◆ setAutoHideDecorations()

◆ paintEvent()

◆ changeEvent()

◆ setActive()

◆ windowStateChanged()

◆ updateDecorations()

◆ updateStateButtons()

◆ onMinimized

◆ onMaximized

◆ onRestored

◆ onUndock

◆ onDock

◆ onOnTop

◆ windowTitleChanged

◆ activate()
