This view part provides an editor/viewer for properties of other views. More...

#include <views/PropertyView.h>

Inheritance diagram for PropertyView:

[legend]

Signals
void	viewActivated (ViewPart *view)

void	viewClosed (ViewPart *view)

void	viewDestroyed (ViewPart *view)

void	minimizedRequested (ViewPart *view)

void	currentDockLocationChanged (Qt::DockWidgetArea area)

Public Member Functions
template<typename Reflector >
void	reflect (Reflector &r)

virtual Qt::DockWidgetArea	getDefaultDockArea () const
	Can be implemented by view implementations to provide a preferred default dock area that is assigned by default when the view is created. More...

virtual void	init (IWorkbenchPartSite *site)
	Is called by the workbench. More...

IWorkbenchPartSite *	getSite ()

virtual void	activate ()
	Is called by the Workbench to inform the Part that is being activated by the user. More...

virtual void	deactivate ()
	Is called by the Workbench to inform the Part that is being deactivated since another Part got the focus. More...

bool	isVisible () const

Qt::DockWidgetArea	getDockArea () const
	Returns the dock area, this view belongs to. More...

bool	isActivated () const
	Returns true if this ViewPart currently has the focus and hence the users attention. More...

virtual Object *	getAdapter (const Class &adapter)
	Returns an object which is an instance of the given class associated with this object. More...

Class const &	getClass () const
	call the virtual internalGetClass(). More...

Static Public Member Functions
static PseudoClass const &	CLASS ()

Protected Slots
virtual void	onVisibilityChanged (bool visible)

void	onMinimizeRequested ()

void	onDockLocationChanged (Qt::DockWidgetArea area)

void	onTopLevelChanged (bool topLevel)

Protected Member Functions
virtual QWidget *	createDefaultPage ()
	Must be implemented in derived classes. More...

virtual QWidget *	createPage (IWorkbenchPart *part)
	Must be implemented in derived classes. More...

virtual void	viewActivated (IWorkbenchPart *part)
	Notifies this listener that the given view part has been activated. More...

virtual QWidget *	createPartControl ()
	Creates the content widget. More...

void	setPage (QWidget *page)
	Sets the specified widget as current "page". More...

virtual void	editorActivated (IWorkbenchPart *part)
	Notifies this listener that the given editor part has been activated. More...

virtual void	editorClosed (IWorkbenchPart *part)
	Notifies this listener that the given editor part has been closed. More...

virtual void	viewClosed (IWorkbenchPart *part)
	Notifies this listener that the given view part has been closed. More...

virtual void	focusInEvent (QFocusEvent *)

virtual void	closeEvent (QCloseEvent *)

QMenu *	getViewMenu ()
	Returns the optional view menu that is shown when the user clicks the view menu tool button. More...

ViewPartTitleBar *	getTitleBar ()
	Returns the title bar of this view part. More...

void	paintEvent (QPaintEvent *event)

virtual Class const &	internalGetClass () const =0

Protected Attributes
ViewPartTitleBar *	mTitleBar

Detailed Description

This view part provides an editor/viewer for properties of other views.

If any other view implements the PropertyViewPage adapter its properties are shown in this editor upon activation.

Member Function Documentation

◆ reflect()

void reflect ( Reflector & r )

inline

◆ getDefaultDockArea()

virtual Qt::DockWidgetArea getDefaultDockArea ( ) const

inlinevirtual

Can be implemented by view implementations to provide a preferred default dock area that is assigned by default when the view is created.

The user can move the view freely to other dock areas afterwards. The default implementation will return Qt::LeftDockWidgetArea.

Reimplemented from ViewPart.

◆ createDefaultPage()

virtual QWidget* createDefaultPage ( )

protectedvirtual

Must be implemented in derived classes.

Is called to display a default page (e.g. when no workbench part is active)

Implements PageViewPart.

◆ createPage()

virtual QWidget* createPage ( IWorkbenchPart * part )

protectedvirtual

Must be implemented in derived classes.

Is called when the workbench part changes in order to display a special page for that part. If this method returns NULL, the current page remains unchanged. Note that the creator of the page is responsible for its destruction. The page will not be deleted if this PageViewPart is destructed!

Implements PageViewPart.

◆ viewActivated() [1/2]

virtual void viewActivated ( IWorkbenchPart * part )

protectedvirtual

Notifies this listener that the given view part has been activated.

Reimplemented from PageViewPart.

◆ createPartControl()

virtual QWidget* createPartControl ( )

protectedvirtualinherited

Creates the content widget.

Implements ViewPart.

Reimplemented in VisualizationControl.

◆ setPage()

void setPage ( QWidget * page )

protectedinherited

Sets the specified widget as current "page".

◆ editorActivated()

virtual void editorActivated ( IWorkbenchPart * part )

protectedvirtualinherited

Notifies this listener that the given editor part has been activated.

Implements IPartListener.

◆ editorClosed()

virtual void editorClosed ( IWorkbenchPart * part )

protectedvirtualinherited

Notifies this listener that the given editor part has been closed.

Implements IPartListener.

◆ viewActivated [2/2]

void viewActivated ( ViewPart * view )

signalinherited

◆ viewClosed() [1/2]

virtual void viewClosed ( IWorkbenchPart * part )

protectedvirtualinherited

Notifies this listener that the given view part has been closed.

Implements IPartListener.

◆ viewClosed [2/2]

void viewClosed ( ViewPart * view )

signalinherited

◆ init()

virtual void init ( IWorkbenchPartSite * site )

virtualinherited

Is called by the workbench.

The WorkbenchPart should initialize itself and my store the pointer tothe IWorkbenchPartSite interface for later use.

Implements WorkbenchPart.

◆ getSite()

IWorkbenchPartSite* getSite ( )

inherited

◆ activate()

virtual void activate ( )

virtualinherited

Is called by the Workbench to inform the Part that is being activated by the user.

Reimplemented from WorkbenchPart.

◆ deactivate()

virtual void deactivate ( )

virtualinherited

Is called by the Workbench to inform the Part that is being deactivated since another Part got the focus.

Reimplemented from WorkbenchPart.

◆ isVisible()

bool isVisible ( ) const

inherited

◆ getDockArea()

Qt::DockWidgetArea getDockArea ( ) const

inherited

Returns the dock area, this view belongs to.

◆ focusInEvent()

virtual void focusInEvent ( QFocusEvent * )

protectedvirtualinherited

◆ closeEvent()

virtual void closeEvent ( QCloseEvent * )

protectedvirtualinherited

◆ getViewMenu()

QMenu* getViewMenu ( )

protectedinherited

Returns the optional view menu that is shown when the user clicks the view menu tool button.

A ViewPart can add items to this menu within it's createPartControl() method, by calling this method and populating items to the menu.

◆ getTitleBar()

ViewPartTitleBar* getTitleBar ( )

protectedinherited

Returns the title bar of this view part.

◆ paintEvent()

void paintEvent ( QPaintEvent * event )

protectedinherited

◆ viewDestroyed

void viewDestroyed ( ViewPart * view )

signalinherited

◆ minimizedRequested

void minimizedRequested ( ViewPart * view )

signalinherited

◆ currentDockLocationChanged

void currentDockLocationChanged ( Qt::DockWidgetArea area )

signalinherited

◆ onVisibilityChanged

virtual void onVisibilityChanged ( bool visible )

protectedvirtualslotinherited

◆ onMinimizeRequested

void onMinimizeRequested ( )

protectedslotinherited

◆ onDockLocationChanged

void onDockLocationChanged ( Qt::DockWidgetArea area )

protectedslotinherited

◆ onTopLevelChanged

void onTopLevelChanged ( bool topLevel )

protectedslotinherited

◆ isActivated()

bool isActivated ( ) const

inlineinherited

Returns true if this ViewPart currently has the focus and hence the users attention.

◆ getAdapter()

virtual Object* getAdapter ( const Class & adapter )

inlinevirtualinherited

Returns an object which is an instance of the given class associated with this object.

Returns nullptr if no such object can be found. The implementation if IAdaptable is responsible for destroying the instance of the created object.

Implements IAdaptable.

Reimplemented in VisualizationView.

◆ getClass()

Class const& getClass ( ) const

inlineinherited

call the virtual internalGetClass().

◆ CLASS()

static PseudoClass const& CLASS ( )

inlinestaticinherited

◆ internalGetClass()

virtual Class const& internalGetClass ( ) const

protectedpure virtualinherited

Member Data Documentation

◆ mTitleBar

ViewPartTitleBar* mTitleBar

protectedinherited

The documentation for this class was generated from the following file:

gui/include/views/PropertyView.h
