FormulaeColormap Class Reference

A class for creating formula based color maps. More...

#include <image/Colormap.h>

Inheritance diagram for FormulaeColormap:

Public Types
typedef iterator	const_iterator

Public Member Functions
	FormulaeColormap (std::size_t size=256)
	FormulaeColormap (int rformula, int gformula, int bformula, std::size_t size=256)
void	setFormulae (int rformula, int gformula, int bformula)
	Sets the formulae for the color components. More...
virtual Color::RGB	getf (float f) const
	Accesses the continuous colors. More...
void	resize (std::size_t pSize)
	Sets a certain size of this colormap. More...
virtual std::size_t	size () const
	Returns the set size. More...
virtual Color::RGB	get (std::size_t idx) const
	Returns the color at the specified index (must be >= 0 and < size) More...
Color::RGB	operator() (std::size_t idx)
	Returns the color in the colormap at the given index. More...
Color::RGB	operator[] (std::size_t idx)
	Returns the color in the colormap at the given index. More...
iterator	begin ()
	Gives an iterator to the beginning of the colormap. More...
const_iterator	begin () const
	Gives a const iterator to the beginning of the colormap. More...
iterator	end ()
	Gives an iterator to the end of the colormap. More...
const_iterator	end () const
	Gives an const iterator to the end of the colormap. More...
Class const &	getClass () const
	call the virtual internalGetClass(). More...

Static Public Member Functions
static PseudoClass const &	CLASS ()

Protected Member Functions
virtual Class const &	internalGetClass () const =0

Detailed Description

A class for creating formula based color maps.

For each RGB color component a formula is given, that specifies, how the component is computed. The advantage of these color maps is, that most of the formulae are at least 2 times differentiable and therefore no changes in the color gradients are visible (which is the case in linear gradient color maps).

The following predefined formulas are available. They correspond to the rgbformulae of gnuplot:

    0: 0               1: 0.5             2: 1
    3: x               4: x^2             5: x^3
    6: x^4             7: sqrt(x)         8: sqrt(sqrt(x))
    9: sin(90x)       10: cos(90x)       11: |x-0.5|
   12: (2x-1)^2       13: sin(180x)      14: |cos(180x)|
   15: sin(360x)      16: cos(360x)      17: |sin(360x)|
   18: |cos(360x)|    19: |sin(720x)|    20: |cos(720x)|
   21: 3x             22: 3x-1           23: 3x-2
   24: |3x-1|         25: |3x-2|         26: (3x-1)/2
   27: (3x-2)/2       28: |(3x-1)/2|     29: |(3x-2)/2|
   30: x/0.32-0.78125 31: 2*x-0.84       32: 4x;1;-2x+1.84;x/0.08-11.5
   33: |2*x - 0.5|    34: 2*x            35: 2*x - 0.5
   36: 2*x - 1

Member Typedef Documentation

const_iterator

typedef iterator const_iterator

inherited

Constructor & Destructor Documentation

FormulaeColormap() [1/2]

FormulaeColormap ( std::size_t  size = 256 )

inline

FormulaeColormap() [2/2]

FormulaeColormap ( int  rformula, int  gformula, int  bformula, std::size_t  size = 256  )

inline

Member Function Documentation

setFormulae()

void setFormulae ( int  rformula, int  gformula, int  bformula  )

inline

Sets the formulae for the color components.

getf()

virtual Color::RGB getf ( float  f ) const

virtualinherited

Accesses the continuous colors.

The specified floating point value must be within the interval [0,1].

Implements ContinuousColormap.

resize()

void resize ( std::size_t  pSize )

inlineinherited

Sets a certain size of this colormap.

size()

virtual std::size_t size ( ) const

inlinevirtualinherited

Returns the set size.

Implements Colormap.

get()

virtual Color::RGB get ( std::size_t  idx ) const

inlinevirtualinherited

Returns the color at the specified index (must be >= 0 and < size)

Implements Colormap.

operator()()

Color::RGB operator() ( std::size_t  idx )

inlineinherited

Returns the color in the colormap at the given index.

operator[]()

Color::RGB operator[] ( std::size_t  idx )

inlineinherited

Returns the color in the colormap at the given index.

begin() [1/2]

iterator begin ( )

inlineinherited

Gives an iterator to the beginning of the colormap.

begin() [2/2]

const_iterator begin ( ) const

inlineinherited

Gives a const iterator to the beginning of the colormap.

end() [1/2]

iterator end ( )

inlineinherited

Gives an iterator to the end of the colormap.

end() [2/2]

const_iterator end ( ) const

inlineinherited

Gives an const iterator to the end of the colormap.

getClass()

Class const& getClass ( ) const

inlineinherited

call the virtual internalGetClass().

CLASS()

static PseudoClass const& CLASS ( )

inlinestaticinherited

internalGetClass()

virtual Class const& internalGetClass ( ) const

protectedpure virtualinherited

---

The documentation for this class was generated from the following file:

• base/include/image/Colormap.h
