DiagnosticsModule Class Reference

Base class for modules that want to use diagnostics and set the current status. More...

#include <fw/Status.h>

Inheritance diagram for DiagnosticsModule:

Public Types
typedef std::map< std::string, Status >	StatusMap

Public Member Functions
	DiagnosticsModule (const std::string &name="")
virtual	~DiagnosticsModule ()
void	setHeartbeatInterval (const Duration &interval)
	Set the watchdog interval. More...
void	setName (const std::string &name)
Duration	getHeartbeatInterval () const
	Return the watchdog interval. More...
void	heartbeat ()
	When called for the first time heartbeat usage will be enabled. More...
bool	hasHeartbeatTimeout () const
	Returns true if heartbeat usage is enabled (by first call to heartbeat()) and last heartbeat was more than heartbeat interval time ago. More...
void	bootup (const std::string &message, const std::string &trText="")
	Signal that the module is booting up. More...
void	bootupFinished ()
	Signal that the module has finished booting up (There can still be errors but booting up is finished) More...
void	recoverFinished ()
	Signal that the module has finished recovering (There can still be errors but recovering is finished) More...
void	recover (const std::string &message, const std::string &trText="")
	Signal that the module is recovering. More...
void	ok (const std::string &category="")
	Signal that a category contains no more errors. More...
bool	warning (const std::string &category, const std::string &message, const std::string &trText="")
	Signal a warning in a category. More...
bool	error (const std::string &category, const std::string &message, const std::string &trText="")
	Signal an error in a category. More...
bool	setStatus (Status::StatusMode mode, const std::string &category, const std::string &message, const std::string &trText="")
	Set the status of a given category. More...
Status::StatusMode	getStatus () const
	Get the status mode defined by the status of the watchdog (if used) and the bootup, error and warning methods. More...
StatusMap	getStatusMap () const
	Gets the current status map containing all errors, warnings and bootup messages. More...

Protected Attributes
boost::optional< Status >	mBootUpStatus
boost::optional< Status >	mRecoverStatus
Duration	mHeartbeatInterval
boost::optional< Time >	mLastHeartbeat
StatusMap	mStatusMap
std::string	mName

Detailed Description

Base class for modules that want to use diagnostics and set the current status.

Classes inheriting this class can be added to the StatusManager for obtaining an overall state of one or multiple diagnostic modules.

Member Typedef Documentation

StatusMap

typedef std::map<std::string, Status> StatusMap

Constructor & Destructor Documentation

DiagnosticsModule()

DiagnosticsModule ( const std::string &  name = "" )

inline

~DiagnosticsModule()

virtual ~DiagnosticsModule ( )

inlinevirtual

Member Function Documentation

setHeartbeatInterval()

void setHeartbeatInterval ( const Duration &  interval )

inline

Set the watchdog interval.

setName()

void setName ( const std::string &  name )

inline

getHeartbeatInterval()

Duration getHeartbeatInterval ( ) const

inline

Return the watchdog interval.

heartbeat()

void heartbeat ( )

inline

When called for the first time heartbeat usage will be enabled.

This resets the watchdog and signal that everything is working. If you call heartbeat in an interval < watchdog interval the status will be OK (if no other error is set) If a module blocks or fails and does not call heartbeat again until the watchdog interval passed the status will be ERROR

hasHeartbeatTimeout()

bool hasHeartbeatTimeout ( ) const

inline

Returns true if heartbeat usage is enabled (by first call to heartbeat()) and last heartbeat was more than heartbeat interval time ago.

bootup()

void bootup	(	const std::string &	message,
		const std::string &	trText = ""
	)

Signal that the module is booting up.

Optional a message text and a text used for translation can be specified

bootupFinished()

void bootupFinished

(

)

Signal that the module has finished booting up (There can still be errors but booting up is finished)

recoverFinished()

void recoverFinished

(

)

Signal that the module has finished recovering (There can still be errors but recovering is finished)

recover()

void recover	(	const std::string &	message,
		const std::string &	trText = ""
	)

Signal that the module is recovering.

Optional a message text and a text used for translation can be specified

ok()

void ok

(

const std::string &

category = ""

)

Signal that a category contains no more errors.

If no category is set all categories are cleared (except boot up).

warning()

bool warning	(	const std::string &	category,
		const std::string &	message,
		const std::string &	trText = ""
	)

Signal a warning in a category.

A message and an optional text for translation can be given. Additionally, the message is written to the error log.

Returns

true if warning was set, false if a warning with same text was already set

error()

bool error	(	const std::string &	category,
		const std::string &	message,
		const std::string &	trText = ""
	)

Signal an error in a category.

A message and an optional text for translation can be given. Additionally, the error message is written to the error log.

Returns

true if error was set, false if a error with same text was already set

setStatus()

bool setStatus	(	Status::StatusMode	mode,
		const std::string &	category,
		const std::string &	message,
		const std::string &	trText = ""
	)

Set the status of a given category.

This method can be used to set the warning or error status of the specified category. a message and an optional text for translation can be given. This method essentially does the same as the above warning() and error() methods. In contrast to those two methods, this method does NOT write the error message to the error/warning log. Hence, it can be used to set the error and warning status silently. In all other cases the warning() and error() methods should be used, which are more convenient.

Returns

true if error was set, false if a error with same text was already set

getStatus()

Status::StatusMode getStatus

(

)

const

Get the status mode defined by the status of the watchdog (if used) and the bootup, error and warning methods.

If the watchdog is used (watchdog is enabled when calling heartbeat() for the first time) this method tests if the latest reset of the watchdog was inside the specified watchdog interval. If not it will return ERROR.

getStatusMap()

StatusMap getStatusMap

(

)

const

Gets the current status map containing all errors, warnings and bootup messages.

Member Data Documentation

mBootUpStatus

boost::optional<Status> mBootUpStatus

protected

mRecoverStatus

boost::optional<Status> mRecoverStatus

protected

mHeartbeatInterval

Duration mHeartbeatInterval

protected

mLastHeartbeat

boost::optional<Time> mLastHeartbeat

protected

mStatusMap

StatusMap mStatusMap

protected

mName

std::string mName

protected

---

The documentation for this class was generated from the following file:

• framework/include/fw/Status.h
