This is the abstract base class of local and remote authority classes. More...

#include <fw/AbstractAuthority.h>

Inheritance diagram for AbstractAuthority:

[legend]

Public Types
typedef std::multimap< std::string, std::string >	ChannelNameMapping

typedef std::map< std::string, Status >	ChannelStatusMap

Public Member Functions
virtual	~AbstractAuthority ()

virtual StatusManager::StatusMap	getStatusMap ()=0
	Return a status map that contains the status of the authority as well as all registered submodules. More...

virtual boost::shared_ptr< PropertyNode >	getProperties ()=0
	Returns the main property node of this Authority. More...

virtual std::set< std::string >	getPublishedChannels ()=0
	Returns all published channels by this authority (and its sub-authorities) More...

virtual std::set< std::string >	getSubscribedChannels ()=0
	Returns all subscribed channels by this authority (and its sub-authorities) More...

virtual std::set< std::string >	getServiceInterfaces ()=0
	Returns all service interfaces provided by this authority. More...

virtual ChannelNameMapping	getPublishedChannelNames ()=0
	Returns all published channels (pair of global and local names) by this authority (and its sub-authorities) More...

virtual ChannelNameMapping	getSubscribedChannelNames ()=0
	Returns all subscribed channels (pair of global and local names) by this authority (and its sub-authorities) More...

virtual ChannelStatusMap	getSubscribedChannelStatus ()=0
	Returns status for all subscribed channels (ok, no publisher, no data, ...) by this authority (and its sub-authorities) More...

virtual void	start ()=0
	Starts/Resumes the authority. More...

virtual void	stop ()=0
	Stops/Pauses the authority. To continue call start(). More...

virtual bool	hasUnrecoverableFailure () const =0
	Returns true, if there was a failure while processing the immediate handlers. More...

virtual bool	isStarted () const =0
	Returns true, if the authority was started (by calling start()). More...

virtual bool	isRunning () const =0
	Return if the authority is running. More...

Detailed Information Retrieval
These methods allow to obtain detailed information on the Authority.
std::string	getNamespace () const
	Return the resolved namespace of the authority. More...

std::string	getGlobalName () const
	Return the fully qualified global name (includes namespace) This method returns the name without the trailing UUID added if the authority is anonymous. More...

std::string	getGlobalID () const
	Return the fully qualified global id (includes namespace) More...

std::string	getID () const
	Return the id of the authority. More...

std::string	getName () const
	Return the name of the authority. More...

const AuthorityDescription &	getDescription () const
	Return the description of this authority. More...

Protected Attributes
AuthorityDescription	mDescription

Detailed Description

This is the abstract base class of local and remote authority classes.

It provides access to properties of the authority like name, id, namespace and status informations. The methods of this class are implemented by Authority and RemoteAuthority.

Member Typedef Documentation

◆ ChannelNameMapping

typedef std::multimap<std::string, std::string> ChannelNameMapping

◆ ChannelStatusMap

typedef std::map<std::string, Status> ChannelStatusMap

Constructor & Destructor Documentation

◆ ~AbstractAuthority()

virtual ~AbstractAuthority ( )

inlinevirtual

Member Function Documentation

◆ getNamespace()

std::string getNamespace ( ) const

inline

Return the resolved namespace of the authority.

Returns: Namespace

◆ getGlobalName()

std::string getGlobalName ( ) const

inline

Return the fully qualified global name (includes namespace) This method returns the name without the trailing UUID added if the authority is anonymous.

Use getGlobalID() to obtain the unique id of the authority.

Returns: Global Name

◆ getGlobalID()

std::string getGlobalID ( ) const

inline

Return the fully qualified global id (includes namespace)

Returns: Global ID

◆ getID()

std::string getID ( ) const

inline

Return the id of the authority.

Returns: ID

◆ getName()

std::string getName ( ) const

inline

Return the name of the authority.

Returns: Name of this authority

◆ getDescription()

const AuthorityDescription& getDescription ( ) const

inline

Return the description of this authority.

◆ getStatusMap()

virtual StatusManager::StatusMap getStatusMap ( )

pure virtual

Return a status map that contains the status of the authority as well as all registered submodules.

Implemented in Authority, and RemoteAuthority.

◆ getProperties()

virtual boost::shared_ptr<PropertyNode> getProperties ( )

pure virtual

Returns the main property node of this Authority.

Implemented in Authority, RemoteAuthority, and MicroUnit.

◆ getPublishedChannels()

virtual std::set<std::string> getPublishedChannels ( )

pure virtual

Returns all published channels by this authority (and its sub-authorities)

Implemented in Authority, and RemoteAuthority.

◆ getSubscribedChannels()

virtual std::set<std::string> getSubscribedChannels ( )

pure virtual

Returns all subscribed channels by this authority (and its sub-authorities)

Implemented in Authority, and RemoteAuthority.

◆ getServiceInterfaces()

virtual std::set<std::string> getServiceInterfaces ( )

pure virtual

Returns all service interfaces provided by this authority.

Implemented in Authority, and RemoteAuthority.

◆ getPublishedChannelNames()

virtual ChannelNameMapping getPublishedChannelNames ( )

pure virtual

Returns all published channels (pair of global and local names) by this authority (and its sub-authorities)

Implemented in Authority, and RemoteAuthority.

◆ getSubscribedChannelNames()

virtual ChannelNameMapping getSubscribedChannelNames ( )

pure virtual

Returns all subscribed channels (pair of global and local names) by this authority (and its sub-authorities)

Implemented in Authority, and RemoteAuthority.

◆ getSubscribedChannelStatus()

virtual ChannelStatusMap getSubscribedChannelStatus ( )

pure virtual

Returns status for all subscribed channels (ok, no publisher, no data, ...) by this authority (and its sub-authorities)

Implemented in Authority, and RemoteAuthority.

◆ start()

virtual void start ( )

pure virtual

Starts/Resumes the authority.

Implemented in Authority, RemoteAuthority, Unit, MicroUnit, and QtUnit.

◆ stop()

virtual void stop ( )

pure virtual

Stops/Pauses the authority. To continue call start().

Implemented in Authority, RemoteAuthority, Unit, and MicroUnit.

◆ hasUnrecoverableFailure()

virtual bool hasUnrecoverableFailure ( ) const

pure virtual

Returns true, if there was a failure while processing the immediate handlers.

This is an unrecoverable failure that will disallow the further execution of the authority.

Implemented in Authority, and RemoteAuthority.

◆ isStarted()

virtual bool isStarted ( ) const

pure virtual

Returns true, if the authority was started (by calling start()).

It will return false, if the authority was not yet started or stopped.

Implemented in Authority, and RemoteAuthority.

◆ isRunning()

virtual bool isRunning ( ) const

pure virtual

Return if the authority is running.

Implemented in Authority, and RemoteAuthority.

Member Data Documentation

◆ mDescription

AuthorityDescription mDescription

protected

The documentation for this class was generated from the following file:

framework/include/fw/AbstractAuthority.h
