Base class of connections between frameworks. More...

#include <fw/RemoteConnection.h>

Inheritance diagram for RemoteConnection:

[legend]

Classes
class	RPCRemoteFinishHandler
	RPCHandler for getting notified when an rpc call on server side is finished and the response is ready. More...

class	RPCRemoteRequestHandler
	RPCHandler for sending a rpc call to the server side. More...

struct	SendData

Public Types
typedef std::map< std::string, Typename >	ChannelTypeMap

typedef std::set< std::string >	StringSet

typedef std::map< std::string, SendData >	ChannelSendMap

typedef std::set< std::string >	MetaSet

typedef std::list< AuthorityDescription >	AuthorityDescriptions

Public Member Functions
virtual	~RemoteConnection ()
	Destructor. More...

template<typename Reflector >
void	reflect (Reflector &r)

boost::asio::ip::tcp::socket &	getSocket ()
	Returns the network socket of this connection. More...

virtual void	start ()
	Starts the connection. Can be implemented in derived classes. More...

void	stop ()
	Close the socket. More...

void	onConnect (bool enablePTPTimeSync, bool enablePingTimeout)
	Called by RemoteModule::onIncomingConnected/onOutgoingConnected. More...

bool	isPTPSyncEnabled ()
	Is synchronization of clocks via PTP enabled? More...

bool	isPingTimeoutEnabled ()
	Is ping timeout enabled? More...

void	startTimeSync ()
	Create a timer to frequently call syncTime. More...

bool	isSynchronized () const
	synchronizeFrameworks() was executed. More...

virtual void	publishChannels (const ChannelTypeMap &channels)=0
	Notifies the connected framework that we have at least one publisher for each of the channels in the channels map. More...

void	unpublishChannel (const std::string &channel)
	Notifies the connected framework that we no longer have a publisher for the given channel. More...

virtual void	subscribeChannel (const std::string &channelID, const ServiceLevel &serviceLevel)=0
	Notify the connected remote frameworks that we have a subscriber for the given channel (assuming it has a publisher for it). More...

virtual void	publishAuthorities (const AuthorityDescriptions &authorities)=0
	Notifies the connected framework that the authorities in the authorities map exist in our framework. More...

virtual void	unpublishAuthorities (const AuthorityDescriptions &authorities)=0
	Notifies the connected framework that the authorities in the authorities map do not longer exist in our framework. More...

void	migrateUnit (const std::string &id)
	Send a request to the connected framework to transfer ownership of a unit to this framework. More...

bool	hasAuthority (const std::string &id) const
	Check if a authority with given full id exists in the connected framework. More...

virtual void	publishServices (const StringSet &services)=0
	Notifies the connected framework that the services in the services set exist in our framework. More...

virtual void	unpublishServices (const StringSet &services)=0
	Notifies the connected framework that the services in the services set do not longer exist in our framework. More...

template<typename BufferSequence >
void	write (const BufferSequence &buffers)
	Send data in the buffers to the connected framework. More...

UUID	getRemoteID () const

std::string	getGlobalID () const

void	setAuthority (std::unique_ptr< Authority > auth)

const std::string &	getFrameworkID () const

const KnownFramework &	getAddress () const

void	setAddress (const KnownFramework &addr)

void	setAutoReconnect (bool autoReconnect)

Class const &	getClass () const
	call the virtual internalGetClass(). More...

Static Public Member Functions
static PseudoClass const &	CLASS ()

Protected Types
enum	AuthState { AUTHSTATE_NONE, AUTHSTATE_CONNECTING, AUTHSTATE_AUTHENTICATING, AUTHSTATE_ACCEPTED, AUTHSTATE_DENIED }

typedef std::pair< FrameworkMessageType, Buffer< uint8 > >	RPCMessage

Protected Member Functions
	RemoteConnection ()
	Constructs a remote connection that uses its own io service. More...

	RemoteConnection (boost::asio::io_service &service)
	Constructs a remote connection that uses a given io service. More...

virtual void	onDisconnect ()
	Called in stop() when connection is about to be stopped. More...

virtual void	onWriteError (boost::system::system_error &e)
	Called when writing to the socket failed. Can be implemented in derived classes. More...

void	syncTime ()
	Time synchronization between frameworks. More...

void	sendPTP ()
	Sends a PTP command used for time synchronization between frameworks. More...

void	ping ()
	Sends a ping command. More...

bool	hasPingTimeout () const
	Check if the connection incoming ping's are still alive. More...

void	writeMessage (FrameworkMessageType msg)
	Writes a message to the other framework. More...

template<typename Arg , typename... Args>
void	writeMessage (FrameworkMessageType msg, Arg &&arg, Args &&... args)
	Writes a message to the other framework. More...

template<typename BufferType >
void	writeMessageFromBuffer (FrameworkMessageType msg, const BufferType &buffer)
	Writes a message to the other framework. More...

template<typename DataType >
void	writeMessageFromData (FrameworkMessageType msg, const DataType &data)
	Writes a message to the other framework. More...

void	queueRPCMessage (FrameworkMessageType msg, Buffer< uint8 > &&answer)
	Queue an outgoing RPC request or RPC response to be transmitted in a separate thread. More...

void	valueChanged (ChannelRead< void > value, ServiceLevel &serviceLevel)
	Channel callback method that gets registered on each channel the connected framework subscribes. More...

void	parseMessage ()
	Parses an incoming message (stored in mMessage) and calls the respective receivedXXX method. More...

void	receivedPTPFollowUp (uint64 timestamp)

void	receivedPTPDelayResponse (uint64 timestamp)

void	receivedPTPDelayRequest (uint64 timestamp)

void	receivedPTPFinish ()

void	receivedSubscribeChannelRequest ()

void	receivedUnsubscribeChannelRequest (const std::string &channelID)

void	receivedPublishChannelMsg ()

void	receivedUnpublishChannelMsg ()

void	receivedPublishAuthorityMsg ()

void	receivedUnpublishAuthorityMsg ()

virtual void	receivedPublishServiceMsg ()=0

void	receivedUnpublishServiceMsg ()

void	receivedWriteChannelMsg ()

virtual void	receivedRPCRequestMsg ()=0

virtual void	receivedRPCResponseMsg ()=0

void	receivedRequestMigrationMsg ()

void	receivedMigrationMsg ()

void	receivedMigrationSinkSuccessMsg ()

void	receivedMigrationSinkFailureMsg ()

void	receivedMigrationFinishedMsg ()

void	receivedTypeMetaMsg ()

void	receivedChannelMetaMsg ()

void	receivedPingMsg ()

virtual void	sendData (ChannelRead< void > value, ServiceLevel &serviceLevel)

virtual int	addBinaryFormatVersion (Buffer< uint8 > &data)=0

void	synchronizeFrameworks ()

void	updateOutgoingStats (std::size_t size)

bool	checkMessageHeader () const
	Returns true, if the message (header) is valid, i.e. More...

void	sendConnectDenied (const std::string &msg)

void	sendRPCMessagesThread ()

void	processPingThread ()

void	checkPingTimeoutThread ()

void	sendChannelUpdatesThread ()

virtual Class const &	internalGetClass () const =0

Protected Attributes
KnownFramework	address
	The address of the connected framework. More...

UUID	remoteID
	The UUID of the connected framework. More...

std::string	frameworkID
	The ID/Name of the connected framework. More...

uint32	remoteVersion
	The protocol version of the connected framework. More...

std::unique_ptr< Authority >	authority
	Our authority used for subscribing to data. More...

ChannelSendMap	subscriptions
	List of channels the connected framework is subscribed to + what was sent to them. More...

MetaSet	sentMetaInformation
	Set of type meta information already sent. More...

StringSet	publishedServices
	List of services of the connected framework. More...

Time	synchronizedTime
	Time when the connection was fully established (e.g. PTP synchronized) More...

bool	mEnablePTPSync
	PTP Sync enabled for this connection? More...

bool	mEnablePingTimeout
	Ping timeout enabled for this connection? More...

TimeOffsetCompensation	clockOffset
	The clock offset between us and the connected framework. More...

IOService	mService

boost::asio::ip::tcp::socket	mSocket

boost::condition_variable	mRPCMessagesCondition

boost::mutex	mWriteMutex

boost::mutex	mStopMutex

TimerPtr	mSyncTimeTimer

boost::thread	mSendRPCMessagesThread

boost::thread	mProcessPingThread

boost::thread	mCheckPingTimeoutThread

boost::thread	mSendChannelUpdatesThread

Time	mHeaderReceived

FrameworkMessageHeader	mHeader

Buffer< uint8 >	mMessage

AuthState	mAuthState

std::string	mAuthSignMsg

bool	mPTPOutgoing

Time	mPTPSyncLocal

Time	mPTPSyncRemote

Time	mPTPDelayLocal

Time	mPTPDelayRemote

Time	mLastPTP

Time	mPingLastSend

Time	mPingLastReceived

boost::shared_ptr< MicroUnit >	mMigrationUnit

std::string	mMigrationNS

std::string	mMigrationID

bool	mStopped

boost::shared_ptr< RPCRemoteFinishHandler >	mRPCFinishHandler

boost::shared_ptr< RPCRemoteRequestHandler >	mRPCRequestHandler

std::map< std::string, boost::shared_ptr< RemoteAuthority > >	mRemoteAuthorities

std::list< RPCMessage >	mOutgoingRPCMessages

boost::mutex	mRPCMessagesMutex

std::unordered_map< std::string, ServiceLevel >	mPendingChannelUpdates

boost::mutex	mChannelUpdatesMutex

Detailed Description

Base class of connections between frameworks.

If PTP synchronization is enabled for a connection, the protocol for establishing a time sync (determining a time offset) between two connected frameworks is as follows:

      RemoteConnection in                                  RemoteConnection in
          Framework A                                          Framework B
               |                                                    |
               | PTP_SYNC_MSG                                       |
               |--------------------------------------------------->| take timestamp
take timestamp |                                                    | as PTPSyncLocal (T1')
               | PTP_FOLLOW_UP_MSG: timestamp                       |
               |--------------------------------------------------->| store received timestamp
               |                                                    | as PTPSyncRemote (T1)
               | PTP_DELAY_REQUEST_MSG                              |
               |<---------------------------------------------------|
take timestamp |                                                    | take timestamp
               |                                                    | as PTPDelayLocal (T2)
               | PTP_DELAY_RESPONSE_MSG: timestamp                  |
               |--------------------------------------------------->| store received timestamp
               |                                                    | as PTPDelayRemote (T2'),
               |                                                    | calculate offset
               |                                                    |  = (T1'-T1-T2'+T2)/2
               | PTP_FINISH_MSG                                     |
               |<---------------------------------------------------|
               |                                                    |
               | PUBLISH_CHANNEL_MSG: channels                      |
               |--------------------------------------------------->|
               | PUBLISH_SERVICE_MSG: services                      |
               |--------------------------------------------------->|
               | PUBLISH_AUTHORITY_MSG: authorities                 |
               |--------------------------------------------------->|

If PTP synchronization is not enabled, the PUBLISH_CHANNEL/SERVICE/AUTHORITY_MSG messages are sent immediately.

Member Typedef Documentation

◆ ChannelTypeMap

typedef std::map<std::string, Typename> ChannelTypeMap

◆ StringSet

typedef std::set<std::string> StringSet

◆ ChannelSendMap

typedef std::map<std::string, SendData> ChannelSendMap

◆ MetaSet

typedef std::set<std::string> MetaSet

◆ AuthorityDescriptions

typedef std::list<AuthorityDescription> AuthorityDescriptions

◆ RPCMessage

typedef std::pair<FrameworkMessageType, Buffer<uint8> > RPCMessage

protected

Member Enumeration Documentation

◆ AuthState

enum AuthState

protected

Enumerator
AUTHSTATE_NONE
AUTHSTATE_CONNECTING
AUTHSTATE_AUTHENTICATING
AUTHSTATE_ACCEPTED
AUTHSTATE_DENIED

Constructor & Destructor Documentation

◆ RemoteConnection() [1/2]

RemoteConnection ( )

protected

Constructs a remote connection that uses its own io service.

run()/runThreads() must be called on the service by the subclass!

◆ RemoteConnection() [2/2]

RemoteConnection ( boost::asio::io_service & service )

protected

Constructs a remote connection that uses a given io service.

run()/runThreads() must be called on the service by the owner!

◆ ~RemoteConnection()

virtual ~RemoteConnection ( )

virtual

Destructor.

Member Function Documentation

◆ reflect()

void reflect ( Reflector & r )

inline

◆ getSocket()

boost::asio::ip::tcp::socket& getSocket ( )

inline

Returns the network socket of this connection.

◆ start()

virtual void start ( )

virtual

Starts the connection. Can be implemented in derived classes.

Reimplemented in RemoteOutgoingConnectionBase, and RemoteIncomingConnection.

◆ stop()

void stop ( )

Close the socket.

◆ onConnect()

void onConnect	(	bool	enablePTPTimeSync,
		bool	enablePingTimeout
	)

Called by RemoteModule::onIncomingConnected/onOutgoingConnected.

Provides the RemoteModule settings for enabling PTP sync and ping timeout, which should be kept by the RemoteConnection through its lifetime.

◆ isPTPSyncEnabled()

bool isPTPSyncEnabled ( )

inline

Is synchronization of clocks via PTP enabled?

◆ isPingTimeoutEnabled()

bool isPingTimeoutEnabled ( )

inline

Is ping timeout enabled?

◆ startTimeSync()

void startTimeSync ( )

Create a timer to frequently call syncTime.

Time sync must be completed at least once before data is transmitted (if ping timeout is enabled in the RemoteModule, time sync is automatically done in the ping thread and the timer should not be created).

◆ isSynchronized()

bool isSynchronized ( ) const

inline

synchronizeFrameworks() was executed.

The connection is fully established, time was synchronized at least once (if enabled and required) and authorities/channels/services have been published to the remote framework (unless monitor-only).

◆ publishChannels()

virtual void publishChannels ( const ChannelTypeMap & channels )

pure virtual

Notifies the connected framework that we have at least one publisher for each of the channels in the channels map.

Implemented in ConcreteRemoteConnection< BinaryFormatVersion >, and ConcreteRemoteConnection< 2 >.

◆ unpublishChannel()

void unpublishChannel ( const std::string & channel )

Notifies the connected framework that we no longer have a publisher for the given channel.

◆ subscribeChannel()

virtual void subscribeChannel	(	const std::string &	channelID,
		const ServiceLevel &	serviceLevel
	)

pure virtual

Notify the connected remote frameworks that we have a subscriber for the given channel (assuming it has a publisher for it).

Implemented in ConcreteRemoteConnection< BinaryFormatVersion >, and ConcreteRemoteConnection< 2 >.

◆ publishAuthorities()

virtual void publishAuthorities ( const AuthorityDescriptions & authorities )

pure virtual

Notifies the connected framework that the authorities in the authorities map exist in our framework.

Implemented in ConcreteRemoteConnection< BinaryFormatVersion >, and ConcreteRemoteConnection< 2 >.

◆ unpublishAuthorities()

virtual void unpublishAuthorities ( const AuthorityDescriptions & authorities )

pure virtual

Notifies the connected framework that the authorities in the authorities map do not longer exist in our framework.

Implemented in ConcreteRemoteConnection< BinaryFormatVersion >, and ConcreteRemoteConnection< 2 >.

◆ migrateUnit()

void migrateUnit ( const std::string & id )

Send a request to the connected framework to transfer ownership of a unit to this framework.

◆ hasAuthority()

bool hasAuthority ( const std::string & id ) const

Check if a authority with given full id exists in the connected framework.

◆ publishServices()

virtual void publishServices ( const StringSet & services )

pure virtual

Notifies the connected framework that the services in the services set exist in our framework.

Implemented in ConcreteRemoteConnection< BinaryFormatVersion >, and ConcreteRemoteConnection< 2 >.

◆ unpublishServices()

virtual void unpublishServices ( const StringSet & services )

pure virtual

Notifies the connected framework that the services in the services set do not longer exist in our framework.

Implemented in ConcreteRemoteConnection< BinaryFormatVersion >, and ConcreteRemoteConnection< 2 >.

◆ write()

void write ( const BufferSequence & buffers )

inline

Send data in the buffers to the connected framework.

Parameters

[in] buffers The data to send

◆ getRemoteID()

UUID getRemoteID ( ) const

inline

◆ getGlobalID()

std::string getGlobalID ( ) const

inline

◆ setAuthority()

void setAuthority ( std::unique_ptr< Authority > auth )

inline

◆ getFrameworkID()

const std::string& getFrameworkID ( ) const

inline

◆ getAddress()

const KnownFramework& getAddress ( ) const

inline

◆ setAddress()

void setAddress ( const KnownFramework & addr )

inline

◆ setAutoReconnect()

void setAutoReconnect ( bool autoReconnect )

inline

◆ onDisconnect()

virtual void onDisconnect ( )

inlineprotectedvirtual

Called in stop() when connection is about to be stopped.

Can be implemented in derived classes.

Reimplemented in RemoteOutgoingConnectionBase, and RemoteIncomingConnection.

◆ onWriteError()

virtual void onWriteError ( boost::system::system_error & e )

inlineprotectedvirtual

Called when writing to the socket failed. Can be implemented in derived classes.

Reimplemented in RemoteOutgoingConnectionBase.

◆ syncTime()

void syncTime ( )

protected

Time synchronization between frameworks.

For local connected frameworks the method synchronizeFrameworks will be called. For frameworks on remote hosts sendPTP will be called.

◆ sendPTP()

void sendPTP ( )

protected

Sends a PTP command used for time synchronization between frameworks.

◆ ping()

void ping ( )

protected

Sends a ping command.

This method ensures, that the ping is not send more than the configured interval in the RemoteModule.

◆ hasPingTimeout()

bool hasPingTimeout ( ) const

protected

Check if the connection incoming ping's are still alive.

◆ writeMessage() [1/2]

void writeMessage ( FrameworkMessageType msg )

inlineprotected

Writes a message to the other framework.

This method takes just the message type.

◆ writeMessage() [2/2]

void writeMessage	(	FrameworkMessageType	msg,
		Arg &&	arg,
		Args &&...	args
	)

inlineprotected

Writes a message to the other framework.

This method takes the message type and a variable number of parameters that are sent within the message.

◆ writeMessageFromBuffer()

void writeMessageFromBuffer	(	FrameworkMessageType	msg,
		const BufferType &	buffer
	)

inlineprotected

Writes a message to the other framework.

Instead of writing parameters into a buffer for generating the message, this method expects a buffer as parameter directly, e.g. created by serializing data.

◆ writeMessageFromData()

void writeMessageFromData	(	FrameworkMessageType	msg,
		const DataType &	data
	)

inlineprotected

Writes a message to the other framework.

Instead of writing the parameter into a buffer for generating the message, (as writeMessage does), this method uses the parameter memory location directly.

◆ queueRPCMessage()

void queueRPCMessage	(	FrameworkMessageType	msg,
		Buffer< uint8 > &&	answer
	)

protected

Queue an outgoing RPC request or RPC response to be transmitted in a separate thread.

msg must be either RPC_RESPONSE_MSG or RPC_REQUEST_MSG

◆ valueChanged()

void valueChanged	(	ChannelRead< void >	value,
		ServiceLevel &	serviceLevel
	)

protected

Channel callback method that gets registered on each channel the connected framework subscribes.

When data in the channel changes it is sent to the connected framework.

◆ parseMessage()

void parseMessage ( )

protected

Parses an incoming message (stored in mMessage) and calls the respective receivedXXX method.

◆ receivedPTPFollowUp()

void receivedPTPFollowUp ( uint64 timestamp )

protected

◆ receivedPTPDelayResponse()

void receivedPTPDelayResponse ( uint64 timestamp )

protected

◆ receivedPTPDelayRequest()

void receivedPTPDelayRequest ( uint64 timestamp )

protected

◆ receivedPTPFinish()

void receivedPTPFinish ( )

protected

◆ receivedSubscribeChannelRequest()

void receivedSubscribeChannelRequest ( )

protected

◆ receivedUnsubscribeChannelRequest()

void receivedUnsubscribeChannelRequest ( const std::string & channelID )

protected

◆ receivedPublishChannelMsg()

void receivedPublishChannelMsg ( )

protected

◆ receivedUnpublishChannelMsg()

void receivedUnpublishChannelMsg ( )

protected

◆ receivedPublishAuthorityMsg()

void receivedPublishAuthorityMsg ( )

protected

◆ receivedUnpublishAuthorityMsg()

void receivedUnpublishAuthorityMsg ( )

protected

◆ receivedPublishServiceMsg()

virtual void receivedPublishServiceMsg ( )

protectedpure virtual

Implemented in ConcreteRemoteConnection< BinaryFormatVersion >, and ConcreteRemoteConnection< 2 >.

◆ receivedUnpublishServiceMsg()

void receivedUnpublishServiceMsg ( )

protected

◆ receivedWriteChannelMsg()

void receivedWriteChannelMsg ( )

protected

◆ receivedRPCRequestMsg()

virtual void receivedRPCRequestMsg ( )

protectedpure virtual

Implemented in ConcreteRemoteConnection< BinaryFormatVersion >, and ConcreteRemoteConnection< 2 >.

◆ receivedRPCResponseMsg()

virtual void receivedRPCResponseMsg ( )

protectedpure virtual

Implemented in ConcreteRemoteConnection< BinaryFormatVersion >, and ConcreteRemoteConnection< 2 >.

◆ receivedRequestMigrationMsg()

void receivedRequestMigrationMsg ( )

protected

◆ receivedMigrationMsg()

void receivedMigrationMsg ( )

protected

◆ receivedMigrationSinkSuccessMsg()

void receivedMigrationSinkSuccessMsg ( )

protected

◆ receivedMigrationSinkFailureMsg()

void receivedMigrationSinkFailureMsg ( )

protected

◆ receivedMigrationFinishedMsg()

void receivedMigrationFinishedMsg ( )

protected

◆ receivedTypeMetaMsg()

void receivedTypeMetaMsg ( )

protected

◆ receivedChannelMetaMsg()

void receivedChannelMetaMsg ( )

protected

◆ receivedPingMsg()

void receivedPingMsg ( )

protected

◆ sendData()

virtual void sendData	(	ChannelRead< void >	value,
		ServiceLevel &	serviceLevel
	)

inlineprotectedvirtual

Reimplemented in ConcreteRemoteConnection< BinaryFormatVersion >, and ConcreteRemoteConnection< 2 >.

◆ addBinaryFormatVersion()

virtual int addBinaryFormatVersion ( Buffer< uint8 > & data )

protectedpure virtual

Implemented in ConcreteRemoteConnection< BinaryFormatVersion >, and ConcreteRemoteConnection< 2 >.

◆ synchronizeFrameworks()

void synchronizeFrameworks ( )

protected

◆ updateOutgoingStats()

void updateOutgoingStats ( std::size_t size )

protected

◆ checkMessageHeader()

bool checkMessageHeader ( ) const

protected

Returns true, if the message (header) is valid, i.e.

if the specified message length does not exceed a max size and the message type is known. This is used to prevent Denial of Service attacks.

◆ sendConnectDenied()

void sendConnectDenied ( const std::string & msg )

protected

◆ sendRPCMessagesThread()

void sendRPCMessagesThread ( )

protected

◆ processPingThread()

void processPingThread ( )

protected

◆ checkPingTimeoutThread()

void checkPingTimeoutThread ( )

protected

◆ sendChannelUpdatesThread()

void sendChannelUpdatesThread ( )

protected

◆ getClass()

Class const& getClass ( ) const

inlineinherited

call the virtual internalGetClass().

◆ CLASS()

static PseudoClass const& CLASS ( )

inlinestaticinherited

◆ internalGetClass()

virtual Class const& internalGetClass ( ) const

protectedpure virtualinherited

Member Data Documentation

◆ address

KnownFramework address

protected

The address of the connected framework.

◆ remoteID

UUID remoteID

protected

The UUID of the connected framework.

◆ frameworkID

std::string frameworkID

protected

The ID/Name of the connected framework.

◆ remoteVersion

uint32 remoteVersion

protected

The protocol version of the connected framework.

◆ authority

std::unique_ptr<Authority> authority

protected

Our authority used for subscribing to data.

◆ subscriptions

ChannelSendMap subscriptions

protected

List of channels the connected framework is subscribed to + what was sent to them.

◆ sentMetaInformation

MetaSet sentMetaInformation

protected

Set of type meta information already sent.

◆ publishedServices

StringSet publishedServices

protected

List of services of the connected framework.

◆ synchronizedTime

Time synchronizedTime

protected

Time when the connection was fully established (e.g. PTP synchronized)

◆ mEnablePTPSync

bool mEnablePTPSync

protected

PTP Sync enabled for this connection?

◆ mEnablePingTimeout

bool mEnablePingTimeout

protected

Ping timeout enabled for this connection?

◆ clockOffset

TimeOffsetCompensation clockOffset

protected

The clock offset between us and the connected framework.

◆ mService

IOService mService

protected

◆ mSocket

boost::asio::ip::tcp::socket mSocket

protected

◆ mRPCMessagesCondition

boost::condition_variable mRPCMessagesCondition

protected

◆ mWriteMutex

boost::mutex mWriteMutex

protected

◆ mStopMutex

boost::mutex mStopMutex

protected

◆ mSyncTimeTimer

TimerPtr mSyncTimeTimer

protected

◆ mSendRPCMessagesThread

boost::thread mSendRPCMessagesThread

protected

◆ mProcessPingThread

boost::thread mProcessPingThread

protected

◆ mCheckPingTimeoutThread

boost::thread mCheckPingTimeoutThread

protected

◆ mSendChannelUpdatesThread

boost::thread mSendChannelUpdatesThread

protected

◆ mHeaderReceived

Time mHeaderReceived

protected

◆ mHeader

FrameworkMessageHeader mHeader

protected

◆ mMessage

Buffer<uint8> mMessage

protected

◆ mAuthState

AuthState mAuthState

protected

◆ mAuthSignMsg

std::string mAuthSignMsg

protected

◆ mPTPOutgoing

bool mPTPOutgoing

protected

◆ mPTPSyncLocal

Time mPTPSyncLocal

protected

◆ mPTPSyncRemote

Time mPTPSyncRemote

protected

◆ mPTPDelayLocal

Time mPTPDelayLocal

protected

◆ mPTPDelayRemote

Time mPTPDelayRemote

protected

◆ mLastPTP

Time mLastPTP

protected

◆ mPingLastSend

Time mPingLastSend

protected

◆ mPingLastReceived

Time mPingLastReceived

protected

◆ mMigrationUnit

boost::shared_ptr<MicroUnit> mMigrationUnit

protected

◆ mMigrationNS

std::string mMigrationNS

protected

◆ mMigrationID

std::string mMigrationID

protected

◆ mStopped

bool mStopped

protected

◆ mRPCFinishHandler

boost::shared_ptr<RPCRemoteFinishHandler> mRPCFinishHandler

protected

◆ mRPCRequestHandler

boost::shared_ptr<RPCRemoteRequestHandler> mRPCRequestHandler

protected

◆ mRemoteAuthorities

std::map<std::string, boost::shared_ptr<RemoteAuthority> > mRemoteAuthorities

protected

◆ mOutgoingRPCMessages

std::list<RPCMessage> mOutgoingRPCMessages

protected

◆ mRPCMessagesMutex

boost::mutex mRPCMessagesMutex

protected

◆ mPendingChannelUpdates

std::unordered_map<std::string, ServiceLevel> mPendingChannelUpdates

protected

◆ mChannelUpdatesMutex

boost::mutex mChannelUpdatesMutex

protected

The documentation for this class was generated from the following file:

framework/include/fw/RemoteConnection.h

Classes

Public Types

Public Member Functions

Static Public Member Functions

Protected Types

Protected Member Functions

Protected Attributes

Detailed Description

Member Typedef Documentation

◆ ChannelTypeMap

◆ StringSet

◆ ChannelSendMap

◆ MetaSet

◆ AuthorityDescriptions

◆ RPCMessage

Member Enumeration Documentation

◆ AuthState

Constructor & Destructor Documentation

◆ RemoteConnection() [1/2]

◆ RemoteConnection() [2/2]

◆ ~RemoteConnection()

Member Function Documentation

◆ reflect()

◆ getSocket()

◆ start()

◆ stop()

◆ onConnect()

◆ isPTPSyncEnabled()

◆ isPingTimeoutEnabled()

◆ startTimeSync()

◆ isSynchronized()

◆ publishChannels()

◆ unpublishChannel()

◆ subscribeChannel()

◆ publishAuthorities()

◆ unpublishAuthorities()

◆ migrateUnit()

◆ hasAuthority()

◆ publishServices()

◆ unpublishServices()

◆ write()

◆ getRemoteID()

◆ getGlobalID()

◆ setAuthority()

◆ getFrameworkID()

◆ getAddress()

◆ setAddress()

◆ setAutoReconnect()

◆ onDisconnect()

◆ onWriteError()

◆ syncTime()

◆ sendPTP()

◆ ping()

◆ hasPingTimeout()

◆ writeMessage() [1/2]

◆ writeMessage() [2/2]

◆ writeMessageFromBuffer()

◆ writeMessageFromData()

◆ queueRPCMessage()

◆ valueChanged()

◆ parseMessage()

◆ receivedPTPFollowUp()

◆ receivedPTPDelayResponse()

◆ receivedPTPDelayRequest()

◆ receivedPTPFinish()

◆ receivedSubscribeChannelRequest()

◆ receivedUnsubscribeChannelRequest()

◆ receivedPublishChannelMsg()

◆ receivedUnpublishChannelMsg()

◆ receivedPublishAuthorityMsg()

◆ receivedUnpublishAuthorityMsg()

◆ receivedPublishServiceMsg()

◆ receivedUnpublishServiceMsg()

◆ receivedWriteChannelMsg()

◆ receivedRPCRequestMsg()

◆ receivedRPCResponseMsg()

◆ receivedRequestMigrationMsg()

◆ receivedMigrationMsg()

◆ receivedMigrationSinkSuccessMsg()

◆ receivedMigrationSinkFailureMsg()
