This class represents the core element of a modular application. More...

#include <fw/Framework.h>

Inheritance diagram for Framework:

[legend]

Public Types
typedef ProtecteeMixin< MetaTypeDatabase >	ProtecteeDatabase

typedef Base::Type	Type

Public Member Functions
	Framework (int argc, char **argv, bool startImmediately=false)
	Constructor that takes command line arguments and a flag. More...

	Framework (const std::vector< std::string > &args, bool startImmediately=false)
	Constructor that takes command line arguments as a vector and a flag. More...

virtual	~Framework ()

template<typename Reflector >
void	reflect (Reflector &r)
	Reflect method for serialization. More...

boost::shared_ptr< PropertyNode >	getProperties ()

void	load (XMLDom &xml)
	Loads the specified XML configuration and applies all registered Loaders on it. More...

void	load (const std::string &configFile)
	Opens the specified XML configuration file and applies all registered Loaders on it. More...

void	load ()
	Loads configuration files given on command line if any by calling above load(const std::string& configFile) function. More...

void	start ()
	Starts the framework and it's remote component (if one was configured or created) and returns immediately. More...

bool	isStarted () const
	Return true if framework is started. More...

Duration	getUptime () const
	Return duration since started. More...

virtual int	exec ()
	Executes the framework and blocks until the framework is terminated, e.g. More...

virtual void	requestTermination (int exitcode=0)
	Requests the termination of the framework and hence the whole application. More...

virtual bool	isTerminationRequested () const
	Returns whether the termination of the framework is reqested. More...

int	getTerminationExitCode () const
	Returns the exit code as specified by requestTermination(), or 0 if requestTermination() was not called. More...

int	run ()
	Calls the above load() and start() methods according to the command line parameters that were passed in the constructor and finally calls exec(). More...

std::string	getID () const
	Returns the ID of this framework. More...

std::string	getGlobalID () const
	Return the fully qualified global id of this framework (includes namespace) More...

XMLVariablesMap &	getVariables ()
	Returns the list of variables that are registered via command line or config file. More...

XMLDomPreprocessor &	getXMLDomPreprocessor ()

ScopedAccess< ProtecteeDatabase >	getMetaDatabase ()
	Return the meta database that contains all known meta information in this framework. More...

bool	isInExec () const

Obtain access to framework components
NameRegistry &	getNameRegistry ()
	Returns the reference to the name registry. More...

AuthorityManager &	getAuthorityManager ()
	Returns the reference to the manager singleton for registered authorities. More...

ChannelManager &	getChannelManager ()
	Returns the reference to the manager singleton for channels. More...

boost::shared_ptr< FrameworkTransformer >	getTransformer ()
	Returns the pointer to the transform framework. More...

ConfigurationLoader &	getConfigurationLoader ()
	Returns the reference to the configuration file loader. More...

boost::shared_ptr< UnitManager >	getUnitManager ()
	Returns the reference to the unit manager. More...

RPCManager &	getRPCManager ()
	Returns the reference to the manager singleton for registered RPC services. More...

boost::shared_ptr< ErrorService >	getErrorService ()
	Returns the pointer to the persistent error service. More...

boost::shared_ptr< RemoteModule >	getRemoteModule ()
	Returns the pointer to the remote module. More...

Static Public Member Functions
static Type &	instance ()
	Returns a reference to the singleton instance. More...

static bool	isDestroyed ()
	Returns true, if the singleton was already destroyed. More...

Protected Member Functions
void	initialize ()

void	finalize ()

void	ctrlCHandler (const IntSignal &sig)

Static Protected Member Functions
static void	errorHandler (const IntSignal &sig)

static bool	enterLeaveErrorHandler (bool enter)

Protected Attributes
bool	mTerminationRequested

int	mTerminationExitCode

bool	mIsStarted

bool	mInExec

bool	mRemoteDisabled

boost::shared_ptr< Private::FrameworkAuthority >	mAuthority

RootPropertyNode	mPropertiesRoot

boost::shared_ptr< PropertyNode >	mProperties

NameRegistry	mNames

boost::shared_ptr< RemoteModule >	mRemoteModule

RPCManager	mRPCManager

ChannelManager	mChannelManager

AuthorityManager	mAuthorityManager

boost::shared_ptr< FrameworkTransformer >	mTransformer

boost::shared_ptr< UnitManager >	mUnitManager

ConfigurationLoader	mConfigurationLoader

boost::shared_ptr< ErrorService >	mErrorServiceModule

std::string	mName

XMLDomPreprocessor	mXMLPreprocessor

XMLDom	mConfigDom

ProtecteeDatabase	mMetaDatabase

Time	mStartTime

Friends
class	Private::FrameworkStartup

Detailed Description

This class represents the core element of a modular application.

The Framework allows communication between different application parts, so called authorities, via data channels and remote procedure calls. The framework hides implementation details as well as sources, destinations of data and the way of data transmission from the developer of an authority. This allows the user to run the application on his local PC or distributed on PCs in a network without changing a single line of code.

Member Typedef Documentation

◆ ProtecteeDatabase

typedef ProtecteeMixin<MetaTypeDatabase> ProtecteeDatabase

◆ Type

typedef Base::Type Type

inherited

Constructor & Destructor Documentation

◆ Framework() [1/2]

Framework	(	int	argc,
		char **	argv,
		bool	startImmediately = `false`
	)

Constructor that takes command line arguments and a flag.

Parameters

argc	Number of command line arguments.
argv	The command line arguments.
startImmediately	If true the methods load() and start() are called after construction.

◆ Framework() [2/2]

Framework	(	const std::vector< std::string > &	args,
		bool	startImmediately = `false`
	)

Constructor that takes command line arguments as a vector and a flag.

Parameters

args	The command line arguments.
startImmediately	If true the methods load() and start() are called after construction.

◆ ~Framework()

virtual ~Framework ( )

virtual

Member Function Documentation

◆ reflect()

void reflect ( Reflector & r )

inline

Reflect method for serialization.

◆ getProperties()

boost::shared_ptr<PropertyNode> getProperties ( )

inline

◆ load() [1/3]

void load ( XMLDom & xml )

Loads the specified XML configuration and applies all registered Loaders on it.

This will load libraries, instantiate and configure units, etc. This method will do nothing if the xml document is empty.

◆ load() [2/3]

void load ( const std::string & configFile )

Opens the specified XML configuration file and applies all registered Loaders on it.

This will load libraries, instantiate and configure units, etc. This method will do nothing if configFile is empty.

◆ load() [3/3]

void load ( )

Loads configuration files given on command line if any by calling above load(const std::string& configFile) function.

◆ start()

void start ( )

Starts the framework and it's remote component (if one was configured or created) and returns immediately.

◆ isStarted()

bool isStarted ( ) const

inline

Return true if framework is started.

◆ getUptime()

Duration getUptime ( ) const

inline

Return duration since started.

◆ exec()

virtual int exec ( )

virtual

Executes the framework and blocks until the framework is terminated, e.g.

by pressing Ctrl+C. Returns the exit code as specified by requestTermination().

Reimplemented in FrameworkWithGui.

◆ requestTermination()

virtual void requestTermination ( int exitcode = 0 )

virtual

Requests the termination of the framework and hence the whole application.

Is called e.g. when user presses Ctrl+C. You can optionally specify an exit code that will be returned as exit code by exec(). Furthermore, this code is returned by the mira executables (mira, miragui, miracenter, etc.).

Reimplemented in FrameworkWithGui.

◆ isTerminationRequested()

virtual bool isTerminationRequested ( ) const

virtual

Returns whether the termination of the framework is reqested.

◆ getTerminationExitCode()

int getTerminationExitCode ( ) const

Returns the exit code as specified by requestTermination(), or 0 if requestTermination() was not called.

See also: isTerminationRequested().

◆ run()

int run ( )

Calls the above load() and start() methods according to the command line parameters that were passed in the constructor and finally calls exec().

Hence, this method will launch a fully operating framework and blocks until the framework is terminated, e.g. by pressing Ctrl+C. Returns the exit code as specified by requestTermination(), or 0 if no error or exception has occurred, otherwise -1.

◆ getNameRegistry()

NameRegistry& getNameRegistry ( )

inline

Returns the reference to the name registry.

◆ getAuthorityManager()

AuthorityManager& getAuthorityManager ( )

inline

Returns the reference to the manager singleton for registered authorities.

◆ getChannelManager()

ChannelManager& getChannelManager ( )

inline

Returns the reference to the manager singleton for channels.

◆ getTransformer()

boost::shared_ptr<FrameworkTransformer> getTransformer ( )

inline

Returns the pointer to the transform framework.

◆ getConfigurationLoader()

ConfigurationLoader& getConfigurationLoader ( )

inline

Returns the reference to the configuration file loader.

◆ getUnitManager()

boost::shared_ptr<UnitManager> getUnitManager ( )

inline

Returns the reference to the unit manager.

◆ getRPCManager()

RPCManager& getRPCManager ( )

inline

Returns the reference to the manager singleton for registered RPC services.

◆ getErrorService()

boost::shared_ptr<ErrorService> getErrorService ( )

inline

Returns the pointer to the persistent error service.

◆ getRemoteModule()

boost::shared_ptr<RemoteModule> getRemoteModule ( )

inline

Returns the pointer to the remote module.

◆ getID()

std::string getID ( ) const

inline

Returns the ID of this framework.

The ID can be specified via command line. If no ID is specified an UUID based one will be generated.

◆ getGlobalID()

std::string getGlobalID ( ) const

inline

Return the fully qualified global id of this framework (includes namespace)

Returns: Global ID

◆ getVariables()

XMLVariablesMap& getVariables ( )

inline

Returns the list of variables that are registered via command line or config file.

◆ getXMLDomPreprocessor()

XMLDomPreprocessor& getXMLDomPreprocessor ( )

inline

◆ getMetaDatabase()

ScopedAccess<ProtecteeDatabase> getMetaDatabase ( )

inline

Return the meta database that contains all known meta information in this framework.

◆ isInExec()

bool isInExec ( ) const

inline

◆ initialize()

void initialize ( )

protected

◆ finalize()

void finalize ( )

protected

◆ ctrlCHandler()

void ctrlCHandler ( const IntSignal & sig )

protected

◆ errorHandler()

static void errorHandler ( const IntSignal & sig )

staticprotected

◆ enterLeaveErrorHandler()

static bool enterLeaveErrorHandler ( bool enter )

staticprotected

◆ instance()

static Type& instance ( )

inlinestaticinherited

Returns a reference to the singleton instance.

Exceptions

XSingleton If the singleton was already destroyed (dead reference) or not yet created (when using ExplicitInstantiation).

◆ isDestroyed()

static bool isDestroyed ( )

inlinestaticinherited

Returns true, if the singleton was already destroyed.

Trying to access it will result in an exception.

Friends And Related Function Documentation

◆ Private::FrameworkStartup

friend class Private::FrameworkStartup

friend

Member Data Documentation

◆ mTerminationRequested

bool mTerminationRequested

protected

◆ mTerminationExitCode

int mTerminationExitCode

protected

◆ mIsStarted

bool mIsStarted

protected

◆ mInExec

bool mInExec

protected

◆ mRemoteDisabled

bool mRemoteDisabled

protected

◆ mAuthority

boost::shared_ptr<Private::FrameworkAuthority> mAuthority

protected

◆ mPropertiesRoot

RootPropertyNode mPropertiesRoot

protected

◆ mProperties

boost::shared_ptr<PropertyNode> mProperties

protected

◆ mNames

NameRegistry mNames

protected

◆ mRemoteModule

boost::shared_ptr<RemoteModule> mRemoteModule

protected

◆ mRPCManager

RPCManager mRPCManager

protected

◆ mChannelManager

ChannelManager mChannelManager

protected

◆ mAuthorityManager

AuthorityManager mAuthorityManager

protected

◆ mTransformer

boost::shared_ptr<FrameworkTransformer> mTransformer

protected

◆ mUnitManager

boost::shared_ptr<UnitManager> mUnitManager

protected

◆ mConfigurationLoader

ConfigurationLoader mConfigurationLoader

protected

◆ mErrorServiceModule

boost::shared_ptr<ErrorService> mErrorServiceModule

protected

◆ mName

std::string mName

protected

◆ mXMLPreprocessor

XMLDomPreprocessor mXMLPreprocessor

protected

◆ mConfigDom

XMLDom mConfigDom

protected

◆ mMetaDatabase

ProtecteeDatabase mMetaDatabase

protected

◆ mStartTime

Time mStartTime

protected

The documentation for this class was generated from the following file:

framework/include/fw/Framework.h

Public Types

Public Member Functions

Static Public Member Functions

Protected Member Functions

Static Protected Member Functions

Protected Attributes

Friends

Detailed Description

Member Typedef Documentation

◆ ProtecteeDatabase

◆ Type

Constructor & Destructor Documentation

◆ Framework() [1/2]

◆ Framework() [2/2]

◆ ~Framework()

Member Function Documentation

◆ reflect()

◆ getProperties()

◆ load() [1/3]

◆ load() [2/3]

◆ load() [3/3]

◆ start()

◆ isStarted()

◆ getUptime()

◆ exec()

◆ requestTermination()

◆ isTerminationRequested()

◆ getTerminationExitCode()

◆ run()

◆ getNameRegistry()

◆ getAuthorityManager()

◆ getChannelManager()

◆ getTransformer()

◆ getConfigurationLoader()

◆ getUnitManager()

◆ getRPCManager()

◆ getErrorService()

◆ getRemoteModule()

◆ getID()

◆ getGlobalID()

◆ getVariables()

◆ getXMLDomPreprocessor()

◆ getMetaDatabase()

◆ isInExec()

◆ initialize()

◆ finalize()

◆ ctrlCHandler()

◆ errorHandler()

◆ enterLeaveErrorHandler()

◆ instance()

◆ isDestroyed()

Friends And Related Function Documentation

◆ Private::FrameworkStartup

Member Data Documentation

◆ mTerminationRequested

◆ mTerminationExitCode

◆ mIsStarted

◆ mInExec

◆ mRemoteDisabled

◆ mAuthority

◆ mPropertiesRoot

◆ mProperties

◆ mNames

◆ mRemoteModule

◆ mRPCManager

◆ mChannelManager

◆ mAuthorityManager

◆ mTransformer

◆ mUnitManager

◆ mConfigurationLoader

◆ mErrorServiceModule

◆ mName

◆ mXMLPreprocessor

◆ mConfigDom

◆ mMetaDatabase

◆ mStartTime
