EnumToFlags.h File Reference

Macros for generating logical operators for using enum values as flags. More...

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Namespaces
	mira
	specialize cv::DataType for our ImgPixel and inherit from cv::DataType<Vec>

Macros
#define	MIRA_ENUM_TO_FLAGS(EnumType)
	Macro that can be used with enums that contain flags. More...
#define	MIRA_ENUM_TO_FLAGS_INCLASS(EnumType)
	Macro that can be used with enums that contain flags. More...

Detailed Description

Macros for generating logical operators for using enum values as flags.

Author

Erik Einhorn

Date

2010/06/28

Macro Definition Documentation

MIRA_ENUM_TO_FLAGS

#define MIRA_ENUM_TO_FLAGS

(

EnumType

)

Value:

inline EnumType                                                 \
	operator&(EnumType a, EnumType b)                               \
    { return EnumType(static_cast<int>(a) & static_cast<int>(b)); } \
                                                                    \
    inline EnumType                                                 \
	operator|(EnumType a, EnumType b)                               \
    { return EnumType(static_cast<int>(a) | static_cast<int>(b)); } \
                                                                    \
    inline EnumType                                                 \
    operator^(EnumType a, EnumType b)                               \
    { return EnumType(static_cast<int>(a) ^ static_cast<int>(b)); } \
                                                                    \
    inline EnumType&                                                \
    operator|=(EnumType& a, EnumType b)                             \
    { return a = a | b; }                                           \
                                                                    \
    inline EnumType&                                                \
    operator&=(EnumType& a, EnumType b)                             \
    { return a = a & b; }                                           \
                                                                    \
    inline EnumType&                                                \
    operator^=(EnumType& a, EnumType b)                             \
    { return a = a ^ b; }                                           \
                                                                    \
    inline EnumType                                                 \
    operator~(EnumType a)                                           \
    { return EnumType(~static_cast<int>(a)); }

Macro that can be used with enums that contain flags.

The macro generates code for the logical operators &,|,^,~ to allow the enum values to be used as normal flags which would lead to compiler errors if these operators were not defined.

Example:

enum MyFlags
{
    flag1 = 0x0001,
    flag2 = 0x0002,
    flag3 = 0x0004,
    flag4 = 0x0008
}

MIRA_ENUM_TO_FLAGS(MyFlags) // generate logical operators for enum values

...

MyFlags combined = flag1 | flag2 & flag4;
if(combined & flag3) {
    ...
}

MIRA_ENUM_TO_FLAGS_INCLASS

#define MIRA_ENUM_TO_FLAGS_INCLASS

(

EnumType

)

Value:

friend inline EnumType                                          \
	operator&(EnumType a, EnumType b)                               \
    { return EnumType(static_cast<int>(a) & static_cast<int>(b)); } \
                                                                    \
    friend inline EnumType                                          \
	operator|(EnumType a, EnumType b)                               \
    { return EnumType(static_cast<int>(a) | static_cast<int>(b)); } \
                                                                    \
    friend inline EnumType                                          \
    operator^(EnumType a, EnumType b)                               \
    { return EnumType(static_cast<int>(a) ^ static_cast<int>(b)); } \
                                                                    \
    friend inline EnumType&                                         \
    operator|=(EnumType& a, EnumType b)                             \
    { return a = a | b; }                                           \
                                                                    \
    friend inline EnumType&                                         \
    operator&=(EnumType& a, EnumType b)                             \
    { return a = a & b; }                                           \
                                                                    \
    friend inline EnumType&                                         \
    operator^=(EnumType& a, EnumType b)                             \
    { return a = a ^ b; }                                           \
                                                                    \
    friend inline EnumType                                          \
    operator~(EnumType a)                                           \
    { return EnumType(~static_cast<int>(a)); }                      \

Macro that can be used with enums that contain flags.

The macro generates code for the logical operators &,|,^,~ to allow the enum values to be used as normal flags which would lead to compiler errors if these operators were not defined. This macro works just as the MIRA_ENUM_TO_FLAGS macro but can be used for enums that are defined in a class.

Example:

class MyClass
{
public:
    enum MyFlags
    {
        flag1 = 0x0001,
        flag2 = 0x0002,
        flag3 = 0x0004,
        flag4 = 0x0008
    }
    MIRA_ENUM_TO_FLAGS_INCLASS(MyFlags) // generate logical operators for enum values
};

...

MyClass::MyFlags combined = flag1 | flag2 & flag 4;
if(combined & flag3) {
    ...
}
